Panduit G2X2LG6EMI - The G2X2LG6EMI PanelMax Shielded Lead-Free PVC/Aluminum Wide Slot Wiring Duct feature a wide slot/finger design that provides separation and noise emission and is suitable with a range of wire bundle sizes. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 122 F (50 C). Mounting holes provided. 2.0" x 2.0" (50.8 mm x 50.8 mm) and 6' (1.8 m) long. Cover sold separately. Color Light Gray.
Panduit

G2X2LG6EMI

UPC: 074983392568

Documents & Media
BrochureTechnical BulletinTechnical DrawingFull Engineering DrawingInstallation InstructionsVideo Clip

Contact for Pricing

Minimum Qty: 24

Multiplier: 12

*Contact for lower quantities*

Overview

The Panduit G2X2LG6EMI PanelMax Shielded Lead-Free PVC/Aluminum Wide Slot Wiring Duct is engineered for superior wire management and EMI/RFI noise reduction in industrial and commercial applications. This robust wiring duct features a precisely designed wide slot and finger configuration, offering excellent separation for various wire bundle sizes. This design not only facilitates organized routing but also actively mitigates noise emissions, crucial for sensitive electronic environments. Constructed from a durable lead-free PVC and aluminum composite, the G2X2LG6EMI ensures longevity and compliance with environmental standards. It boasts a UL 94 flame class rating of V-0, indicating superior fire resistance, and is UL recognized for continuous use at temperatures up to 122°F (50°C). The integrated mounting holes simplify installation, allowing for secure attachment to panels and equipment. Measuring 2.0 inches by 2.0 inches (50.8 mm x 50.8 mm) and a standard 6-foot (1.8 m) length, this duct provides ample capacity for complex wiring harnesses. The light gray color offers a clean, professional aesthetic. Please note that the cover is sold separately, allowing for customization based on specific application needs. Manufactured in the USA, the G2X2LG6EMI is a reliable choice for professional electrical installations requiring organized, protected, and noise-mitigated wire management. Its wide slot design is particularly beneficial for applications where frequent wire access or changes are anticipated, while the shielded construction offers an added layer of protection against electromagnetic interference. The combination of material strength, flame retardancy, and temperature rating makes it suitable for demanding operational conditions. The UNSPSC code for this product is 39131712.
  • Wide slot/finger design for wire separation and noise emission reduction
  • Lead-free PVC/Aluminum construction for durability and compliance
  • UL 94 V-0 flame class rating for enhanced safety
  • UL recognized continuous-use temperature up to 122°F (50°C)
  • Integrated mounting holes for easy installation

Specifications

Adhesive Backed
Mounting Holes
Application
Wide slot/finger design provides greater sidewall rigidity and can be used in a wide range of applications.
Color
Gray
Color
Grey
Connection
Mounting Holes
Finish
Metallic Foil
Length
NA In.
Material Quality
PVC/Aluminum
Size
2.0 x 2.0
Slot Pitch
0.31 in
Slot Pitch
7.874 mm
Slot Style
Slotted
Standard
RoHS Compliant, UL Recognized, CE Compliant, BABA Compliant
Type
Base Wiring Duct
Width
2.25 in
Width
57.15 mm
Package Dimensions (L x W x H)
9.624 IN x 4.686 IN x 73.123 IN
Package Weight (Imperial)
9.6 lbs
