Contact for Pricing
Overview
- 2-fiber OS2 single-mode construction for long-distance, high-bandwidth applications
- SC APC duplex connectors on both ends for precise alignment and low insertion loss
- 24-meter length with 3mm riser-rated (OFNR) jacket for indoor fire safety compliance
- Designed for structured cabling, backbone, and inter-building connections
- Manufactured by Panduit in the US for reliable performance and quality
Specifications
Application | Provide interconnect and cross-connect of applications in entrance facilities, telecommunications rooms, data centers, at the desk and network applications to interconnect pre-terminated cassettes in main distribution, horizontal distribution, and equipmen |
Boot Type | SC Duplex APC |
Color | Yellow |
Fiber Compatibility* | OS2 9/125um |
Flammability Rating* | Riser (OFNR) |
Length | 944.880000000000000 in |
Length | 23999.952000000000000 mm |
Number of Cores | 2 |
Outside Diameter | 0.11810 in |
Outside Diameter | 3 mm |
Plug Type | SC Duplex APC |
Standard | RoHS Compliant, Meets or exceeds ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-3 (FOCIS-3), TIA-604-10 (FOCIS-10) |
Temperature Rating, Maximum | 158 F |
Temperature Rating, Minimum | 158 F |
Type | OS2 |
Package Dimensions (L x W x H) | 10 IN x 12 IN x 1 IN |
Package Weight (Imperial) | 0.92 lbs |
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color GraySVNDZ-P137GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 13.5, Fits to Conduit Size NW/Metric 17/20, Color Gray
CMSBUSCZBL
The Mini-Com Singlemode Simplex SC Adapter is a small form factor (SFF) adapter with integrated panel retention clips and are TIA/EIA-605 FOCIS-10 compatible. It connects two SC connectors in one module space and features a blue SC simplex fiber adapter along with a black module and has zirconia split sleeves.
Frequently Asked Questions
What is the operating temperature range for installation?
The operating and installation temperature range is -20°C to 70°C for both Riser and LSZH cables.
What types of fiber are available for this product?
The product offers Singlemode fiber types OS2 (G.652.D) and LWP Bend-Insensitive (G.657.A2/B2).
What is the maximum connector insertion loss?
The maximum connector insertion loss is 0.30dB for LC/APC and 0.50dB for SC/APC.
What is the storage temperature range?
The storage and shipping temperature range is -40°C to 70°C.
What are the jacket ratings for the cable?
The cable jacket ratings include Riser (OFNR) and Low Smoke Zero Halogen (LSZH).
How durable are the connectors?
The connectors are rated for 500 cycles of durability.
What standards does this product meet?
The product meets or exceeds ISO/IEC 11801, TIA/EIA-568-C.3, and other relevant standards.
What types of connectors are available?
The connectors available are Simplex or Duplex LC/APC and SC/APC for both ends.
