NSI Industries L8N-142 - 2 Hole Long Barrel Copper Compression Lug with Peep Hole 8 AWG - 1/4" Bolt - 3/4" Hole Spacing Long Barrel Copper Compression Lugs are produced from high conductivity copper tubing. They are tin-plated to provide corrosion low contact resistance. Marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed and to cable manufacturer instructions. Temperature rating 90 degrees C. .
NSI Industries

L8N-142

UPC: 662381336347

Documents & Media
Technical BulletinInstallation Instructions

Contact for Pricing

Overview

The NSI Industries L8N-142 is a high-conductivity copper compression lug designed for reliable electrical connections. This 2-hole, long barrel lug is manufactured from premium copper tubing, ensuring excellent conductivity and low contact resistance. It features a tin plating for enhanced corrosion resistance, making it suitable for demanding applications. The lug is clearly marked with its die index and color-coded for straightforward identification and selection, simplifying inventory management and installation processes. Engineered for robust performance, the L8N-142 is rated for a maximum of 35KV when installed according to cable manufacturer instructions and proper procedures. It operates at a maximum temperature of 90 degrees Celsius, providing durability in various environmental conditions. The lug accommodates 8 AWG wire and utilizes a 1/4" bolt size with a 3/4" hole spacing, offering compatibility with standard mounting hardware. A convenient peep hole allows for visual confirmation of wire insertion, ensuring a secure and complete connection. This lug is manufactured in the USA, adhering to stringent quality standards. Its UNSPSC code is 39121405.
  • Constructed from high-conductivity copper tubing for superior electrical performance.
  • Tin-plated finish provides excellent corrosion resistance and low contact resistance.
  • Marked with die index and color-coded for easy identification and installation.
  • Rated for 35KV maximum when properly installed, suitable for high-voltage applications.
  • Features a peep hole for visual verification of wire insertion and connection integrity.

Specifications

Application
Terminate, Splice, Tap Power Connectors
Cable Size
# 8 AWG (STR)
Color
Red
Environmental Conditions
90 C
Finish
Tin Plated
Material
Copper
Material
Tin-Plated Copper
Mounting
1/4 Mounting Holes IN
Number Of Holes
2
Size
L=2.24 - W=.420 - OD=.295 - ID=.205 IN
Size
8 AWG, 1/4" Bolt, 3/4" Hole Spacing
Special Features
# 8 AWG (STR) - 1/4 Mounting Holes - 3/4 Hole Spacing
Standard
UL486A/B, UL467 (8 AWG -3/0 AWG)
Stud Size
1/4 IN
Type
Long Barrel - Two Hole
Voltage Rating
600 V
Voltage Rating
35 kV
Warranty
1 Year
Package Dimensions (L x W x H)
2.24 IN x 0.42 IN x 0.295 IN
Package Dimensions (L x W x H)
5.6896 cm x 10.668 mm x 7.493 mm
Package Weight (Imperial)
4.000 L
Package Weight (Metric)
1.814 kg
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.

OD581

Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
O' Die for OD581 Mechanical Crimp Tool

OJB

O' Die for OD581 Mechanical Crimp Tool
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD6A

U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.

CD7

U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic

E6-PS-D

Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack

2A-18

Non-Insulated Butt Splice, Length 0.63 Inches, Width 0.13 Inches, Wire Range 22-18 AWG, Copper, Tin Plated, 100 Pack
PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray

A1212SC-G

PVC Coated Junction Box, 12 Inch X 12 Inch X 6 Inch, 14 Gauge, Gray
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray

E989NNJ-5-HD

Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705030R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

How to Install NSI Copper Compression Connectors

Install and crimp NSI copper compression lugs or splices on copper conductors. This guide covers conductor preparation, connector selection, and crimping using approved tools and dies.

Tools needed:

Wire brush, Approved crimp tool or compression tool, Approved dies for the selected connector series, NSI M-250 crimp tool for 250 MCM Class B & C copper cable, NSI M-500 crimp tool for 500 MCM Class B & C copper cable, NSI N12ID dieless crimp tool, NSI N1240 tool

Supplies needed:

Correct NSI copper compression lug or splice connector, Copper conductor, Insulation to be stripped from conductor

  1. Select the correct connector

    Choose the proper NSI lug or splice connector for the conductor size and series being installed. Verify that the connector matches the cable size and the approved tool or die set before starting.

  2. Strip the conductor correctly

    Carefully strip the insulation from the conductor without nicking the strands. Strip only enough length so the conductor can be fully inserted into the connector barrel and completely fill it.

  3. Clean the conductor

    Wire brush the stripped portion of the conductor to remove any oxide film. Keep the conductor clean so the connection seats properly and makes good electrical contact.

  4. Insert the conductor into the barrel

    Insert the stripped conductor completely into the connector barrel. Verify that the conductor is fully seated and that no strands are left outside the barrel.

  5. Crimp the connector

    Use an approved NSI compression tool and the correct die set for the connector series. Follow the barrel markings for suggested crimp locations, and make the required number of crimps; long-barrel lugs and splices require twice as many crimps as shown in the parenthesis.

  6. Verify the finished connection

    Inspect the crimped connector to confirm the conductor is fully inserted and the crimp locations are correct. Ensure the connector is secure and that the installation matches the selected size and tool requirements.
