Overview
- Constructed from high conductivity copper tubing for optimal electrical performance.
- Tin-plated finish for excellent corrosion resistance and low contact resistance.
- Features a peep hole for visual inspection of complete cable insertion.
- Rated for 35kV maximum when properly installed, suitable for high-voltage applications.
- Marked with die index and color-coded for easy identification and tool selection.
Specifications
Application | Terminate, Splice, Tap Power Connectors |
Cable Size | 4/0 AWG (STR) |
Color | Purple |
Environmental Conditions | 90 C |
Finish | Tin Plated |
Material | Copper |
Mounting | 3/8 Mounting Hole IN |
Number Of Holes | 1 |
Size | L=2.79 - W=1.00 - OD=.689 - ID=.547 IN |
Special Features | 4/0 AWG (STR) - 3/8 Mounting Hole |
Standard | UL486A/B |
Stud Size | 3/8 IN |
Type | Long Barrel - One Hole With Peep Hole |
Voltage Rating | 600 V |
Warranty | 1 Year |
Package Dimensions (L x W x H) | 2.795 IN x 1 IN x 0.689 IN |
Package Dimensions (L x W x H) | 7.0993 cm x 25.4 mm x 17.5006 mm |
Package Weight (Imperial) | 3.250 L |
Package Weight (Metric) | 1.474 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
How to Install NSI Copper Compression Connectors
Install and crimp NSI copper compression lugs or splices on copper conductors. Select the correct connector size, prepare the conductor properly, and crimp it using the approved tool and die set.
Tools needed:
Wire brush, Approved crimp tool or press, Approved dies for the selected connector series, NSI M-250 crimp tool (for 250 MCM Class B & C copper cable), NSI M-500 crimp tool (for 500 MCM Class B & C copper cable), NSI N12ID dieless crimp tool, NSI N1240 tool
Supplies needed:
NSI copper compression lug or splice connector sized for the cable, Copper conductor, Wire insulation
- Select the correct connector
Choose the proper NSI lug or splice connector for the cable size and conductor type. Verify that the connector size matches the table and is approved for concentric, compressed, or compact copper conductors.
- Strip the conductor correctly
Carefully strip the insulation from the conductor without nicking the strands. Strip only enough length so the conductor can be fully inserted into the connector barrel and completely fill it.
- Clean the conductor
Wire brush the stripped portion of the conductor to remove oxide films and contamination. Ensure the exposed copper is clean before insertion.
- Insert the conductor fully
Insert the cleaned conductor completely into the connector barrel. Verify that the stripped portion is fully seated and fills the barrel before crimping.
- Crimp with the approved tool
Crimp the connector using the approved NSI tool and the correct die set for the connector series. Follow the barrel markings for suggested crimp locations when using N12ID or N1240 tools, and make the required number of crimps; long-barrel connectors require twice the crimps shown in the table.
- Verify the finished connection
Inspect the crimped connector to confirm it is secure and properly formed. Make sure the conductor has not moved and that the connector is suitable for the installed cable size before energizing the circuit.
