Contact for Pricing
Overview
- Constructed from high conductivity copper tubing for superior electrical performance.
- Tin-plated finish provides excellent corrosion resistance and low contact resistance.
- Long barrel design ensures a secure and reliable crimp connection.
- Features a peep hole for visual confirmation of complete cable insertion.
- UL486A Listed and rated for 35KV maximum when properly installed.
Specifications
Application | Terminate, Splice, Tap Power Connectors |
Cable Size | 4/0 AWG (STR) |
Color | Purple |
Connection Type | Compression Lug |
Environmental Conditions | 90 C |
Finish | Tin Plated |
Material | Copper |
Mounting | 1/4 Mounting Hole IN |
Number Of Holes | 1 |
Size | L=2.795 - W=1.000 - OD=.689 - ID=.547 IN |
Size | 4/0 AWG - 1/4" Bolt |
Special Features | 4/0 AWG (STR) - 1/4 Mounting Hole |
Standard | UL486A/B |
Stud Size | 1/4 IN |
Type | Long Barrel - One Hole With Peep Hole |
Voltage Rating | 600 V |
Voltage Rating | 35 kV |
Warranty | 1 Year |
Package Dimensions (L x W x H) | 2.795 IN x 1 IN x 0.689 IN |
Package Dimensions (L x W x H) | 7.0993 cm x 25.4 mm x 17.5006 mm |
Package Weight (Imperial) | 3.250 L |
Package Weight (Metric) | 1.474 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
How to Install and Crimp NSI Copper Compression Connectors
Install a copper compression lug or splice on a properly sized copper conductor. Select the correct connector, prepare the wire, and crimp it using the approved tool and die set for a secure connection.
Estimated time: 15m
Tools needed:
Wire brush, Approved crimp tool or die set (for example, NSI M-250, NSI M-500, N12ID, or N24
Supplies needed:
NSI copper compression connector (lug or splice) sized for the conductor, Copper conductor cable, Wire connector/terminal as required
- Select the correct connector
Choose a lug or splice that matches the cable size and connector series. Verify the connector is approved for concentric, compressed, or compact copper conductors before starting.
- Strip and clean the conductor
Carefully strip the insulation without nicking the strands, leaving enough exposed conductor to completely fill the connector barrel. Wire brush the stripped conductor to remove oxide films, and keep the conductor clean before insertion.
- Insert the conductor fully
Insert the stripped conductor completely into the connector barrel so the strands fill the barrel fully. Do not leave exposed strands outside the barrel, and confirm the conductor is seated to the end.
- Crimp the connector
Use the approved crimp tool and the correct die listed for the connector size. Crimp at the barrel markings or suggested crimp locations, and make the required number of crimps; long-barrel connectors require twice as many crimps as shown in the chart.
- Verify the finished connection
Inspect the crimped connection to confirm it is secure and properly formed. Ensure the connector is fully compressed on the conductor and that no strands are loose or damaged.
