NSI Industries ITG-6 - The Polaris ITG-6 Grey Multi-Tap Single Side Entry Connector features 2 ports sized for 6 - 14 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each port is specially designed for fine-stranded copper wires and pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing fine-stranded wire applications, including installation in cable trays, troughs, wire-ways, raceways, ducts and motor junction boxes.
NSI Industries

ITG-6

UPC: 662381951403

Contact for Pricing

Minimum Qty: 12

Multiplier: 12

*Contact for lower quantities*

Overview

The Polaris ITG-6 2-Port Single-Side Connector provides the simplest solution for forming a secure connection between two fine-stranded wire conductors in applications including cable trays, troughs, wire-ways, raceways, ducts and motor junction boxes. Sized for 6 - 14 AWG wires and rated for 600V, this pre-insulated connector comes pre-loaded with an oxide inhibitor and installs faster than traditional uninsulated connector options using just a hex key and torque wrench. The aluminum alloy body is wrapped in high-dielectric strength plastisol insulation, which is ergonomically molded to offer a comfortable grip, in addition to being resistant to abrasion, chemicals and UV rays. All-in-one design saves time and supplies on each job by eliminating the need for cover and taping; simply brush the conductors clean, strip back their insulation, insert one conductor into each port and secure the covered pressure screws. The ITG-6 connector is rated for a 90 degrees Celsius operating temperature and copper cables up to max AMP ratings of 75. Polaris pre-insulated connectors are available in a range of port numbers and configurations to fit the needs of any job, including UL-listed parallel configurations. Polaris: the original pre-insulated connector and still the brand most asked for by name.
  • One-Side Wire Entry: Form secure connections between 2 conductors quickly using the single-side entry ports sized for wires between 6 and 14 AWG
  • Fine-Stranded Wires: Specially designed to splice fine-stranded, flexible and extra-flexible copper conductors, including DLO cable and motor lead wires
  • Ergonomic Design: Rounded corners and a smooth exterior finish over the plastisol insulation make Polaris connectors comfortable to grip
  • Removable Plugs: Each port and adjustable set screw is covered by a secure plug to prevent debris, moisture or contaminants from entering the insulated connector
  • Pre-filled Oxide Inhibitor: Both single-side entry ports come pre-filled with an oxide inhibitor gel to prevent corrosion and provide low-contact resistance

Specifications

Application
Wire Termination
Color
Grey
Color
Gray
Copper Conductor Max
75 Amp
Environmental Conditions
90 C
Finish
Plastisol Insulated
Housing Material
Aluminum
Housing Material
Aluminium
Material
Aluminum
Number Of Conductors
2
Number Of Poles
1
Size
L=1.130 - W=1.240 - H=1.370 IN
Special Features
(2) 6-14 AWG Class B,C,D - (2) 6-14 AWG Class K,M,I
Standard
UL 486A/B
Temperature Rating
90 C
Temperature Rating, Maximum
194 F
Temperature Rating, Maximum
90 C
Temperature Rating, Minimum
194 F
Temperature Rating, Minimum
90 C
Type
Multi Cable
Voltage Rating
600 V
Warranty
1 Year
Wire Size
(Class B,C,D) 6-14 AWG - (Class K,M,I) 6-14 AWG
Wire Type
B,C,D,K,M,I
Wire/Cable Class
B,C,D,K,M,I
Package Dimensions (L x W x H)
1.13 IN x 1.24 IN x 1.37 IN
Package Dimensions (L x W x H)
2.8702 cm x 3.1496 cm x 3.4798 cm
Package Weight (Imperial)
0.060 L
Package Weight (Metric)
0.027 kg
