NSI Industries IPLD500-5 - The Polaris IPLD500-5 Multi-Tap Dual-Sided Entry Connector features 5 ports sized for 500 MCM - 4 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
More images

NSI Industries IPLD500-5 The Polaris IPLD500-5 Multi-Tap Dual-Sided Entry Connector features 5 ports sized for…

UPC: 662381925039

Documents & Media
BrochureInstallation Instructions

Contact for Pricing

Minimum Qty: 2

Multiplier: 2

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The NSi Industries Polaris IPLD500-5 Multi-Tap Dual-Sided Entry Connector is a pre-insulated, UL Listed 486B wire connector engineered for secure, high-current splicing of large conductors in industrial and commercial applications. This 5-port connector accommodates wire sizes from 500 MCM down to 4 AWG, supporting both copper and aluminum cables with a dual rating of 806A (copper) and 631A (aluminum). The aluminum alloy body is wrapped in high-dielectric strength plastisol insulation, providing abrasion, chemical, and UV resistance while preventing combustion. Each dual-sided port allows wire entry from either side, eliminating the need for additional covers or taping. The connector features removable access plugs over hex screws for tool-free port closure and precise torque control using a hex key and torque wrench (5/16" hex size, 450 in-lbs torque). Designed for installation in cable trays, panel boards, ducts, raceways, or troughs, the IPLD500-5 measures 9.690" in length, 2.500" in width, and 2.940" in height. It operates at 600V and 90°C, with a cold temperature rating down to -45°C. The all-in-one design reduces installation time and material costs by combining insulation, oxide inhibitor, and mounting functionality in a single unit.
  • Dual-Sided Wire Entry: Form secure connections between 5 conductors quickly using the double-side entry ports sized for wires between 500 MCM and 4 AWG
  • Ergonomic Design: Rounded corners and a smooth exterior finish over the abrasion-resistant plastisol insulation make Polaris connectors comfortable to grip
  • Removable Plugs: Each port and set screw comes with a secure plug to prevent debris from entering the insulated connector
  • Pre-filled Oxide Inhibitor: All 5 dual-sided entry (DSE) ports come pre-filled with an oxide inhibitor gel to prevent corrosion and provide low-contact resistance
  • Parallel Rated: This connector is specifically designed and rated for parallel installation, providing a safe and secure way to handle larger projects

Specifications

Aluminum Conductor Max AMP
631 Amp
Aluminum Conductor Note
Dual Rated for use with copper and or aluminum cables. Not for use with fine-stranded, flexible cables. Parallel Rated to provide safety and NEC compliance when installing parallel runs.
Application
Wire Termination
Color
Black
Copper Conductor Max
806 Amp
Environmental Conditions
90 C
Finish
Plastisol Insulated
Housing Material
Aluminum
Housing Material
Aluminium
Material
Aluminum
Number Of Conductors
5
Number Of Poles
1
Size
L=6.380 - W=2.830 - H=2.910 IN
Special Features
(5) 500 MCM-4 AWG - Dual Rated
Standard
UL 486A/B
Temperature Rating
90 C
Temperature Rating, Maximum
194 F
Temperature Rating, Maximum
90 C
Temperature Rating, Minimum
194 F
Temperature Rating, Minimum
90 C
Type
Double Sided Entry
Voltage Rating
600 V
Warranty
1 Year
Wire Size
500 MCM-4 AWG
Wire Type
Class B & C
Wire/Cable Class
Class B, Class C
Package Dimensions (L x W x H)
6.38 IN x 2.83 IN x 2.91 IN
Package Dimensions (L x W x H)
16.2052 cm x 7.1882 cm x 7.3914 cm
Package Weight (Imperial)
1.310 L
Package Weight (Metric)
0.594 kg
The Polaris ISR-500 Multi-Tap In-Line Entry Connector features 2 ports sized for 500 MCM - 4 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

ISR-500

The Polaris ISR-500 Multi-Tap In-Line Entry Connector features 2 ports sized for 500 MCM - 4 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
Bi-Metal Pin Connectors with Insulating Cover, 600V, Aluminum Cable Size 8 AWG to Copper Pigtail Wire Size 10 AWG, Tin Plated, Die Code 24, Die Color Code Blue

61905A

Bi-Metal Pin Connectors with Insulating Cover, 600V, Aluminum Cable Size 8 AWG to Copper Pigtail Wire Size 10 AWG, Tin Plated, Die Code 24, Die Color Code Blue
Panduit DV18-250B-3K Female Disconnect

DV18-250B-3K

Panduit DV18-250B-3K Female Disconnect
Rectangular Power Connectors, Housing, Receptacle / Plug, Wire-to-Wire, 1 Position, Wire & Cable, UL 94V-2, Power, Panel Mount

53884-1

Rectangular Power Connectors, Housing, Receptacle / Plug, Wire-to-Wire, 1 Position, Wire & Cable, UL 94V-2, Power, Panel Mount
The Polaris IPLD500-6 Multi-Tap Dual-Sided Entry Connector features 6 ports sized for 500 MCM - 4 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

IPLD500-6

The Polaris IPLD500-6 Multi-Tap Dual-Sided Entry Connector features 6 ports sized for 500 MCM - 4 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
The Polaris IPLD750-4 Multi-Tap Dual-Sided Entry Connector features 4 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

IPLD750-4

The Polaris IPLD750-4 Multi-Tap Dual-Sided Entry Connector features 4 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
The Polaris IPLD750-3 Multi-Tap Dual-Sided Entry Connector features 3 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

IPLD750-3

The Polaris IPLD750-3 Multi-Tap Dual-Sided Entry Connector features 3 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
The Polaris IPLD750-5 Multi-Tap Dual-Sided Entry Connector features 5 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.

IPLD750-5

The Polaris IPLD750-5 Multi-Tap Dual-Sided Entry Connector features 5 ports sized for 750 - 250 MCM wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each dual-sided port is pre-loaded with an oxide inhibitor, with removable access plugs over the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing applications, including installation in cable trays, panel boards, ducts, raceways or troughs.
