Contact for Pricing
Overview
- 6-hour variable timing with twist knob (no hold feature)
- Brushed-metal aluminum wallplate for commercial durability
- No neutral required; ideal for retrofit installations
- SPST switch type with 20A/10A contact ratings (125/250/277VAC)
- Supports motor loads up to 1HP (125VAC) or 2HP (250VAC)
Specifications
Action | SPDT |
Application | NSI |
Base | Wall Plate |
Color | Brushed-metal aluminum |
Connection Type | Screw Terminal |
Contact Rating | 125-250-277 VAC |
Current Rating | 20A @125VAC (resistive), 10A @250/277VAC (resistive/inductive) |
Enclosure | Single Gang Wall Plate |
Environmental Conditions | 32-122 F |
Frequency Rating | 50-60 Hz |
Initiation | Contact |
Material | Aluminum |
Mounting | Single Gang Wall Plate |
Mounting Type | Wall Plate |
Number Of Poles | 1 |
Operating Temperature | 32-122 F |
Phase | Single Phase |
Poles | SPST |
Series | C506H |
Size | H=5.00 - W=3.00 IN |
Special Features | No Hold 6 Hour Commercial Grade In Wall Time Switch |
Standard | cULus |
Timing Range | 6 Hour |
Type | Spring Wound In Wall Time Switch-Commercial Grade |
Voltage Rating | 125/250/277 VAC |
Package Dimensions (L x W x H) | 1.231 IN x 1.725 IN x 2.685 IN |
Package Dimensions (L x W x H) | 3.1267 cm x 4.3815 cm x 6.8199 cm |
Package Weight (Imperial) | 0.382 L |
Package Weight (Metric) | 0.173 kg |
TEF4-OFF
TEF4-ON or TEF4-OFF allow time-delayed functions up to 100 s in 3 distinct time ranges, independently of the control system. The time delay ranges are selected by a switch and the time delay can be adjusted by means of a rotary switch. The timing function is activated by closing or opening the device on which the timer is mounted. The OFF-delay version operates without additional control supply.
E101PB
The TORK E101PB 24-Hour Digital Timer is designed for a wide range of applications and has a plastic enclosure for indoor or outdoor use. Automate your home or office to save energy and money using the intuitive programming interface. Features up to 20 different on/off times, a 4-day battery backup, 120 Volt rating and a Noryl plastic cover with a locking hasp. Designed for indoor or outdoor loads such as lights, heaters, air conditioners, water heaters, outdoor signage, sump pumps or ventilation fans.
DTS200B
The TORK DTS200B 365/7-Day Multipurpose Advanced Digital Timer has two channels designed for 30 amp, 120/208-240/277 VAC loads and has a Noryl plastic enclosure with a locking hasp for indoor or outdoor use. Automate your home or office to save energy and money, using the intuitive programming interface to set up to 99 different on/off times each day of the week, with 24 unique holiday blocks. Designed for applications in the home, office, factory, church or school, including lights, heaters or air conditioners, water heaters, school warning signals or traffic lights.
C512HH
The TORK C512HH 12-Hour Spring-Wound In-Wall Twist Timer with a commercial-style metal faceplate is designed to control a variety of indoor appliances, motors and lights. Automate factories, offices or other buildings to save energy and money using the simple twist knob and reliable mechanical timekeeping. Features a HOLD setting to keep power on and fits into a standard electrical box for in-wall mounting. Designed for SPDT switch type on indoor loads such as ventilation fans, lighting, HVAC systems, motors, pumps or air compressors.Frequently Asked Questions about NSI Industries
