Overview
- 480W Three-Phase AC/DC Switching Power Supply
- 48V DC Output Voltage
- IP20 Rated for Protection
- DIN-Rail Mounting for Easy Installation
- Integrated Overload, Over-voltage, and Short-circuit Protections
Specifications
Connection Type | Screw Terminal |
Connection Type | Screw Terminals |
Current Rating | 10A |
Current Rating | 10 A |
IP Rating | IP20 |
Material | Metal |
Mounting Type | DIN-Rail |
Mounting Type | DIN-Rail Mount |
Series | SPD |
Size | 150mm x 124mm x 118.8mm |
Voltage Rating | 48V DC |
Package Dimensions (L x W x H) | 7.5 in x 6.3 in x 4.9 in |
Package Weight (Imperial) | 4.20 lb |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the output power of the Carlo Gavazzi SPD484803?
The Carlo Gavazzi SPD484803 has an output power of 480W.
What is the output voltage of this 3-phase power supply?
This 3-phase power supply provides a 48V DC output voltage.
What type of mounting does the SPD484803 support?
The SPD484803 supports DIN-rail mounting for convenient installation.
What protections are included with the SPD484803?
The SPD484803 includes integrated overload, over-voltage, and short-circuit protections.
What is the IP rating of the Carlo Gavazzi SPD484803?
The Carlo Gavazzi SPD484803 has an IP20 rating.
