Contact for Pricing
Overview
- 260W power budget with adjustable 48-56 VDC output
- Supports AC (100-240 VAC) and DC (110-150 VDC) input
- 1500 VAC output-to-ground isolation for PoE compliance
- PowerBoost provides 20% power reserves
- DC-OK relay contact and high immunity to transients
Specifications
Mounting Type | DIN-Rail |
Voltage Rating | 24V DC |
Package Weight (Imperial) | #N/A lbs |
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
CPP24FMWBLY
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
UTP6AL1MBU
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Frequently Asked Questions
What is the power output range of the PS-260?
The PS-260 has an adjustable output voltage of 48-56 VDC and a power budget of 260 W.
What is the operating temperature range for the PS-260?
The PS-260 can operate in temperatures ranging from -25 to +70 °C.
What input voltage does the PS-260 support?
It supports a wide input voltage range, including 85 to 264 VAC and 88 to 180 VDC.
What is the PowerBoost feature of the PS-260?
PowerBoost allows the PS-260 to provide power reserves of up to 20% for increased flexibility.
What are the dimensions of the PS-260?
The PS-260 has dimensions of 39 mm (W) x 124 mm (H) x 117 mm (D).
What is the MTBF rating for the PS-260?
The MTBF is rated at 699,000 hours at 230 VAC (Siemens SN 29500) and 248,000 hours at 230 VAC (MIL-HDBK 217 F).
What type of isolation does the PS-260 offer?
It features unique 1500 VAC output to ground isolation for PoE standard fulfillment.
Does the PS-260 have any special protection features?
Yes, it has high immunity to transients, power surges, and electromagnetic emissions, with MOV input transient protection.
What is the warranty period for the PS-260?
The PS-260 comes with a 5-year warranty.
Is the PS-260 suitable for PoE applications?
Yes, it is an ideal companion for PoE products and is optimized for Power over Ethernet applications.
