ABB - Process Automation HBX01L - HN800 Bus Extender, Horizontal Left
ABB - Process Automation

HBX01L

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

The ABB HN800 Bus Extender HBX01L is a horizontal left-mounted communication accessory designed for the HN800 I/O bus system. This module connects to the left-hand side of HN800 devices, providing an HN800 connector and a 24 VDC power connection for modular expansion in industrial control environments. The HBX01L is part of ABB's HN800 I/O bus system, a modular platform for distributed I/O applications. It enables horizontal left expansion of HN800 devices, ensuring continued connectivity and power distribution within the system. The module is supplied as a single unit (Qty.: 1) and is manufactured by ABB - Process Automation in Switzerland. It is ideal for applications requiring flexible I/O bus expansion while maintaining power supply integrity. The HN800 bus system supports distributed I/O configurations, making the HBX01L suitable for automation and control systems in manufacturing, process industries, and infrastructure projects.
  • Horizontal left module for HN800 I/O bus expansion
  • Provides HN800 connector and 24 VDC power connection
  • Connects to the left-hand side of HN800 devices
  • Single unit (Qty.: 1) for modular expansion
  • Part of ABB's HN800 I/O bus system for distributed I/O applications

Specifications

Voltage Rating
24 VDC
