ABB - Installation Products UPC22SL - Insulated Bus Connector - Number of Ports 2, 2 1-Bolt Small Terminals with 4 stranded - 500 kcmil, Wire Range 12 solid - 4 stranded for Street Light Option

ABB Installation Products UPC22SL Insulated Bus Connector - Number of Ports 2, 2 1-Bolt Small Terminals with 4 stranded…

UPC: 783786033690

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 40

Multiplier: 40

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB Installation Products UPC22SL Insulated Bus Connector is engineered for reliable electrical connections in demanding applications, particularly for street lighting infrastructure. This 2-pole connector features robust 1-bolt small terminals designed to accommodate a broad range of wire sizes. It supports stranded conductors from 4 AWG up to 500 kcmil, and solid conductors from 12 AWG to 4 AWG. This versatility ensures compatibility with various wiring configurations commonly found in street light installations and other utility projects. The insulated construction of the UPC22SL provides essential protection against accidental contact and environmental factors, contributing to a safer and more durable electrical system. The 1-bolt terminal design offers a secure and straightforward method for making connections, minimizing installation time and potential for error. Each pole is designed for a single bolt connection, simplifying the termination process for both incoming and outgoing conductors. Key specifications include: * **Manufacturer:** ABB - Installation Products * **SKU:** UPC22SL * **Poles:** 2 * **Connection Type:** 1-Bolt Small Terminals * **Wire Range (Stranded):** 4 AWG - 500 kcmil * **Wire Range (Solid):** 12 AWG - 4 AWG * **Material:** Insulated This bus connector is an ideal choice for electrical contractors and utility companies requiring dependable and compliant connection solutions for street lighting, power distribution, and other electrical infrastructure projects where wire range flexibility and secure termination are paramount. The UPC22SL ensures efficient and safe power distribution, meeting the specific needs of its intended applications.
  • 2-Pole Insulated Bus Connector for secure electrical connections
  • Features 1-Bolt Small Terminals for reliable termination
  • Accommodates a wide wire range: 12-4 AWG solid, 4-500 kcmil stranded
  • Specifically designed for street light applications and power distribution
  • Durable insulated construction for enhanced safety and longevity

Specifications

Material
Aluminum, PVC
Type
Bus Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0200 L
Package Weight (Metric)
0.4630 kg
2 Port Aluminum Dual Rated Transformer Stud Connector 350 MCM -6 AWG with 5/8" Stud Aluminum dual rated transformer stud connectors are versatile and reusable set screw connectors made from 6061T-6 aluminum alloy for superior electrical and mechanical performance. Clear plated for low contact resistance- stud is tin plated copper which provides low contact resistance for connection to transformer. For use with copper and aluminum conductors. Meets or exceeds ANSI C119.4 Class A. Rated 600V. Temperature rating 90 degrees C.

TS350-2

2 Port Aluminum Dual Rated Transformer Stud Connector 350 MCM -6 AWG with 5/8" Stud Aluminum dual rated transformer stud connectors are versatile and reusable set screw connectors made from 6061T-6 aluminum alloy for superior electrical and mechanical performance. Clear plated for low contact resistance- stud is tin plated copper which provides low contact resistance for connection to transformer. For use with copper and aluminum conductors. Meets or exceeds ANSI C119.4 Class A. Rated 600V. Temperature rating 90 degrees C.
