ABB - Installation Products TSC 12 TN - NEMA Transformer Spade Adapters - TSC series, Tin Plated Aluminum, 12 Bolt Holes, - .562 inch Diameter - two Rows of 6 on 1.75 inch centers, spade thickness 3/4 inch x 10.5 inch long x 4 inch wide.

ABB Installation Products TSC 12 TN NEMA Transformer Spade Adapters - TSC series, Tin Plated Aluminum, 12 Bolt Holes, - .562…

UPC: 783786085118

Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB TSC 12 TN NEMA Transformer Spade Adapter, part of the TSC series, is engineered for robust electrical connections in demanding industrial applications. Constructed from high-quality tin-plated aluminum, this adapter offers superior conductivity and corrosion resistance, ensuring long-term reliability. Its substantial spade design measures 0.75 inches thick, 10.5 inches long, and 4 inches wide, providing ample surface area for secure connections. Featuring 12 bolt holes with a 0.562-inch diameter, arranged in two rows of six on 1.75-inch centers, the TSC 12 TN facilitates versatile and secure mounting of transformer leads or other high-current conductors. This NEMA-rated adapter is designed to meet stringent electrical standards, making it an ideal choice for power distribution, industrial machinery, and utility infrastructure projects. The tin plating enhances its compatibility with various conductor materials and provides an extra layer of protection against environmental factors. ABB's commitment to quality is evident in the durable construction and precise engineering of the TSC 12 TN, ensuring dependable performance where it matters most. Its substantial dimensions and multiple bolt configurations allow for flexible integration into existing electrical systems, simplifying installation and maintenance. Choose the ABB TSC 12 TN for a reliable, high-capacity spade adapter solution that delivers on performance and longevity.
  • Tin Plated Aluminum construction for conductivity and corrosion resistance.
  • 12 bolt holes (0.562 inch diameter) in two rows of 6 on 1.75 inch centers for versatile mounting.
  • Substantial spade dimensions: 0.75 inch thickness, 10.5 inch length, 4 inch width.
  • NEMA rated for industrial electrical applications.
  • TSC series transformer spade adapter from ABB - Installation Products.

Specifications

Connection
Mechanical
Finish
Tin Plated
Insulation
False
Material
Aluminum
Size
thickness 3/4 inch x 10.5 inch long x 4 inch wide
Type
NEMA Transformer Spade Adapter
Width
4 in
Width
101.6 mm
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
2.8500 L
Package Weight (Metric)
1.2930 kg
Aluminum Insulated Transformer Kit, #12 - 350 kcmil, Aluminum and Copper, Stud size 1 inch, Eight Conductor

ZVW 5033-1 SL-TS

Aluminum Insulated Transformer Kit, #12 - 350 kcmil, Aluminum and Copper, Stud size 1 inch, Eight Conductor
Tin-Plated Copper Eyebolt Adapter, Pin Diameter 3/4 inch, Bolt 1/2 inch, Four hole NEMA Pad.

CEA 4-75-5

Tin-Plated Copper Eyebolt Adapter, Pin Diameter 3/4 inch, Bolt 1/2 inch, Four hole NEMA Pad.
Aluminum Transformer Connector, 1/0 - 750 kcmil, Aluminum and Copper, Bolt size 1/2 inch, Eight Conductor, Lay-In, Spade, with Oxide Inhibitor, Length 6.729 inches

ZBK 4047 C

Aluminum Transformer Connector, 1/0 - 750 kcmil, Aluminum and Copper, Bolt size 1/2 inch, Eight Conductor, Lay-In, Spade, with Oxide Inhibitor, Length 6.729 inches
Aluminum Lay-In Transformer Spade Connectors - ZBK Series, conductor range 1/0-750, mount holes 6, outlets 6, with Oxide Inhibitor, Length 5.098 inches

ZBK 3037 C

Aluminum Lay-In Transformer Spade Connectors - ZBK Series, conductor range 1/0-750, mount holes 6, outlets 6, with Oxide Inhibitor, Length 5.098 inches
Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - vertical cable leads, stud size 3 inch, outlets 8, with Complete Assembly with Insulating Rockets, Water Tight, 9.50 Height, 10.75 tower width

FTT 44-175-30 CUAWR

Copper 175 Series Clamp-On Style Transformer and Network Protection Connectors - vertical cable leads, stud size 3 inch, outlets 8, with Complete Assembly with Insulating Rockets, Water Tight, 9.50 Height, 10.75 tower width
Aluminum Transformer Connector, Ten position/tower, Stud size 3 inch, with Insulating Rockets, 9.50 Height, 13.75 tower width

FTT 55-175-30 AWR

Aluminum Transformer Connector, Ten position/tower, Stud size 3 inch, with Insulating Rockets, 9.50 Height, 13.75 tower width
Aluminum Transformer Spade Connector, Double Row Design, Total 6 Tower/positions, Aluminum and Copper, Water Tight, Assembled with Insulating Rockets, 6-3/4 inch wide. Gray PVC Coating. Includes 12 Screws for Towers. 4-Hole Pad is to one side of Connectors. 4.5 inch long x 4 inch wide x .75 inch thick. 1.75 Hole Spacing.

FTN 175-33 AWR

Aluminum Transformer Spade Connector, Double Row Design, Total 6 Tower/positions, Aluminum and Copper, Water Tight, Assembled with Insulating Rockets, 6-3/4 inch wide. Gray PVC Coating. Includes 12 Screws for Towers. 4-Hole Pad is to one side of Connectors. 4.5 inch long x 4 inch wide x .75 inch thick. 1.75 Hole Spacing.
Aluminum Pad-Mount 175 Series Transformer Spade Connector - Double Row Style, Total Outlets 10 - Two Rows of 5, Length 11 3/4 inch. Black PVC Coating, Includes 20 Screws for Towers. Pad is on Right Hand Side, with 4-Holes, .562 inch Diameter, 4 inch wide x 5.375 inch tall x .75 inch thick. Includes Ten FS 1175 Insulating Rockets. Centerformed Pad. 11-3/4 inch wide x 12.25 inch tall.

FTN 175-55 CPAWR

Aluminum Pad-Mount 175 Series Transformer Spade Connector - Double Row Style, Total Outlets 10 - Two Rows of 5, Length 11 3/4 inch. Black PVC Coating, Includes 20 Screws for Towers. Pad is on Right Hand Side, with 4-Holes, .562 inch Diameter, 4 inch wide x 5.375 inch tall x .75 inch thick. Includes Ten FS 1175 Insulating Rockets. Centerformed Pad. 11-3/4 inch wide x 12.25 inch tall.
