ABB - Installation Products CEA 4-75-5 - Tin-Plated Copper Eyebolt Adapter, Pin Diameter 3/4 inch, Bolt 1/2 inch, Four hole NEMA Pad.

ABB Installation Products CEA 4-75-5 Tin-Plated Copper Eyebolt Adapter, Pin Diameter 3/4 inch, Bolt 1/2 inch, Four hole NEMA…

UPC: 783786843831

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 30

Multiplier: 30

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB CEA 4-75-5 is a tin-plated copper eyebolt adapter designed for secure electrical connections. This adapter features a 3/4 inch pin diameter and a 1/2 inch bolt size, ensuring compatibility with standard hardware. It is equipped with a four-hole NEMA pad, providing a robust and stable mounting platform for various industrial applications. The tin plating on the copper construction offers excellent conductivity and corrosion resistance, crucial for maintaining reliable performance in demanding environments. This component is part of ABB's Installation Products catalog, known for its quality and reliability in electrical infrastructure. The NEMA pad configuration allows for secure attachment to surfaces, facilitating the proper grounding or termination of conductors. Engineered for durability, the CEA 4-75-5 is suitable for use in power distribution systems, substations, and other heavy-duty electrical installations where dependable connections are paramount. Its specific design with a four-hole pattern on the NEMA pad ensures a firm grip and even pressure distribution when fastened, minimizing the risk of loosening over time due to vibration or thermal cycling. The combination of high-quality copper and protective tin plating makes this adapter a long-lasting solution for critical electrical infrastructure projects.
  • Tin-plated copper construction for conductivity and corrosion resistance
  • 3/4 inch pin diameter
  • 1/2 inch bolt size
  • Four-hole NEMA pad for secure mounting
  • ABB Installation Products quality and reliability

Specifications

Finish
Tin Plated
Insulation
False
Material
Tin-Plated Copper
Material
Copper
Nema Rating
Four hole NEMA Pad
Series
CEA 4-75
Size
8 inch long
Size
Pin Diameter: 3/4 inch, Bolt: 1/2 inch
Special Features
Dual Rated, 4-Holes, 3/4 inch Pin
Type
Transformer Eyebolt Adapter
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.8600 L
Package Weight (Metric)
0.8440 kg
