Contact for Pricing
Overview
- Durable PVC construction
- Dimensions: 14.75 inches x 12.88 inches
- Designed for ABB industrial enclosures
- Provides a mounting surface for components
- Includes four mounting screws for installation
Specifications
Application | Any outdoor application, especially where sunlight resistance is an issue |
Color | Gray |
Material | PVC |
Material | Polycarbonate |
Material Quality | Polycarbonate |
Mounting Type | Screw Mounting |
Series | JP |
Size | 14.75" x 12.88" |
Size | 14.75 Inches x 12.88 Inches |
Special Features | Avaible in steel or PVC |
Type | Circuit Safe Enclosure Accessories |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 2.300 L |
Package Weight (Metric) | 1.043 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the JP1614P Enclosure
This guide provides step-by-step instructions for installing the JP1614P enclosure, ensuring proper mounting and assembly for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the enclosure
Secure the JP1614P enclosure to the designated mounting surface using the provided mounting screws. Ensure that the enclosure is level and firmly attached.
- Assemble the cover
Attach the cover sub-assembly to the body of the enclosure. Use the screws provided to secure the cover, ensuring a tight fit to maintain the enclosure's integrity.
- Connect wiring
Strip the ends of the wires and connect them to the terminal connectors inside the enclosure. Use a multimeter to verify that all connections are secure and correctly wired.
- Calibrate the enclosure
Once all connections are made, power on the system and check for proper operation. Adjust any settings as necessary to ensure optimal performance.
