ABB Installation Products IKL66 Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR…
UPC: 783786050352
Documents & Media
Contact for Pricing
Minimum Qty: 100
Multiplier: 100
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 5.5-inch long aluminum splice for heavy-duty overhead services
- Dual-ended design: Pink end for 4/0 conductors, Yellow end for 1/0 conductors
- High-conductivity aluminum construction with solid center barriers
- Stabilized-nylon sleeve provides 600V insulation and tool pressure resistance
- Prefilled with oxide inhibitor to prevent oxidation and moisture ingress
- Color-coded and marked for easy identification and installation
- Complies with ANSI C119.4 for aluminum-to-aluminum or aluminum-to-copper connections
- Includes 5-7/16 inch sleeve for robust conductor overlap
- Requires TX 249, 840 (EEI 11A) dies for installation
Specifications
Application | For Combinations of Aluminum-to-Aluminum and Aluminum-to-Copper Conductors. Use as a low tension reducing sleeve for Insulated Conductor |
Color | Pink/Yellow |
Conductor Range | End A: 4/0 ACSR , 4/0 STR End B: 1/0 ACSR , 1/0 STR |
Connection | Compression |
Connection Type | Compression Splice |
Environmental Conditions | All Seasons / Conditions |
Insulation | Yes |
Material | Aluminum |
Mounting | None |
Number Of Conductors | 2 |
Series | IKL |
Size | 4 Inch |
Size | Splice 4 inch, Sleeve 5-1/2 inch |
Special Features | Pre-insulated for fast, easy installation of large home or commercial service entrances. Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor |
Standard | RUS Listed. Passes the Requirements of ANSI C119.4 |
Type | Compression Splice Service Entrance |
Package Dimensions (L x W x H) | 7.25 IN x 6.5 IN x 4 IN |
Package Dimensions (L x W x H) | 18.415 cm x 16.51 cm x 10.16 cm |
Package Weight (Imperial) | 0.1900 L |
Package Weight (Metric) | 0.0860 kg |
ISE135
Pre-Insulated Service Entry Sleeves 1/0 - 2 Str Pre-insulated service entry sleeves are used for fast and easy installation with standard tools. For combinations of aluminum-aluminum and aluminum-copper conductors. Meets the requirements of ANSI C119.4. Rated 600 Volts.
SAC 1/0 R 2
Aluminum Straight Reducing Splice. 1/0 Stranded - Compressed, 2/0 Compact - Solid to #2 Stranded - Compact, #2 and #1 Compact, #1 Solid. Installing Dies CSA22, 5/8, BG, 243. Length 3 inch. Oil Stop. Oxide Inhibitor. Red Cap, Yellow Cap. Dual Rated for Copper and Aluminum Conductors.
IKL65
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Red End: #2 ASCR, #1 STR, #1 SOL, #1 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve
IKL67
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Gray End: 2/0 ASCR, 2/0 STR, 3/0 CPT, 2/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch SleeveIKL68
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Black End: 3/0 ASCR, 3/0 STR, 4/0 CPT, 3/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve
ICS74-1
Aluminum 2-25/32 inch Service Entrance Compression Splice for Wire Range - End A: 1/0 ASCR, 1/0, Yellow, End B: 8 Stranded, 6 Solid, Green, Die: 5/8. For AL to AL and AL to CU Conductors.IKL69
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch SleeveFrequently Asked Questions
What features aid in cable insertion for IKL66?
The IKL66 splice has solid center barriers and large chamfers for easy cable insertion.
What are the conductor sizes for IKL66?
For IKL66, Conductor A is 1/0 (ACSR, STR, COMPR) and Conductor B is 2/0 (COMPT).
Does the IKL66 splice prevent oxidation and moisture?
Yes, the IKL66 splice is prefilled with an oxide inhibitor to prevent oxidation and keep out moisture.
What insulation voltage does the IKL66 splice provide?
The IKL66 splice features tough stabilized-nylon sleeves that provide reliable 600V insulation.
What material is the IKL66 splice made from?
The IKL66 splice is constructed from aluminum, ensuring high conductivity.
What is the length of the IKL66 splice?
The IKL66 splice, part of the 840 Die Series, is 5 1/2 inches long.
What insulation voltage does the IKL66 splice provide?
The IKL66 splice features tough stabilized-nylon sleeves that provide reliable 600V insulation.
What is the length of the IKL66 splice?
The IKL66 splice, part of the 840 Die Series, is 5 1/2 inches long.
What material is the IKL66 splice made from?
The IKL66 splice is constructed from aluminum, ensuring high conductivity.
Does the IKL66 splice prevent oxidation and moisture?
Yes, the IKL66 splice is prefilled with an oxide inhibitor to prevent oxidation and keep out moisture.
