ABB Installation Products IKL67 Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR…
UPC: 783786050369
Documents & Media
Contact for Pricing
Minimum Qty: 100
Multiplier: 100
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 4-inch aluminum compression splice for 4/0 to 2/0 AWG conductors
- Dual-end design with pink (4/0) and gray (2/0) ends for easy identification
- Includes 5-7/16-inch sleeve and TX 249 840 (EEI 11A) installing dies
- Prefilled with oxide inhibitor to prevent oxidation and moisture ingress
- Meets ANSI C119.4 requirements for aluminum-to-aluminum and aluminum-to-copper connections
Specifications
Application | For Combinations of Aluminum-to-Aluminum and Aluminum-to-Copper Conductors. Use as a low tension reducing sleeve for Insulated Conductor |
Conductor Range | End A: 4/0 ACSR , 4/0 STR , 4/0 COMPR , 250 kmcil COMPT. End B: 2/0 ACSR , 2/0 STR , 2/0 COMPR , 3/0 COMPT |
Connection | Compression |
Environmental Conditions | All Seasons / Conditions |
Insulation | Yes |
Material | Aluminum |
Mounting | None |
Number Of Conductors | 2 |
Size | Splice 4 inch, Sleeve 5-1/2 inch |
Special Features | Pre-insulated for fast, easy installation of large home or commercial service entrances. Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor |
Standard | RUS Listed. Passes the Requirements of ANSI C119.4 / RUS Listed. Passes the Requirements of ANSI C119.4 |
Type | Compression Splice Service Entrance |
Package Dimensions (L x W x H) | 7.4 IN x 6.9 IN x 4.8 IN |
Package Dimensions (L x W x H) | 18.796 cm x 17.526 cm x 12.192 cm |
Package Weight (Imperial) | 0.1700 L |
Package Weight (Metric) | 0.0770 kg |
X 1 N 4020
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 4/0 ACSR, 4/0 Stranded, Gray, End B: 2/0 ACSR, 2/0 Stranded, 3/0 Stranded Compact, Gray, Die: 840. For AL to AL or AL to CU Conductors.
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
IKL68
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Black End: 3/0 ASCR, 3/0 STR, 4/0 CPT, 3/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve
ICS74-1
Aluminum 2-25/32 inch Service Entrance Compression Splice for Wire Range - End A: 1/0 ASCR, 1/0, Yellow, End B: 8 Stranded, 6 Solid, Green, Die: 5/8. For AL to AL and AL to CU Conductors.IKL69
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve
PAE3931-9-2-P
Parallel Groove Clamp, Tin Plated, Galvanized Steel Hardware, Pre-filled with Contact Inhibitor, Conductor Range Main 397.5 ACSR - 3/0 Stranded 2/0 - 6 AR, Tap 3/0 ACSR - 2 Stranded 6 AR, with longer Bolt.Frequently Asked Questions
What is the physical length of the IKL67 splice?
The IKL67 service entrance splice is 5 1/2 inches long.
What industry standards does the IKL67 comply with?
When properly installed on aluminum-to-aluminum or aluminum-to-copper conductors, the IKL67 complies with ANSI C119.4 and is RUS Accepted.
What conductor sizes are compatible with the IKL67?
The IKL67 is compatible with 2/0 conductors for Conductor A and 3/0 conductors for Conductor B.
What is the voltage rating for IKL67 splices?
IKL67 splices provide reliable 600V insulation due to their tough stabilized-nylon sleeves.
What material is the IKL67 splice constructed from?
The IKL67 splice is constructed from aluminum, ensuring high conductivity.
What is the IKL67 product used for?
The IKL67 is an insulated aluminum service entrance compression splice, ideal for heavy-duty overhead services.
What is the IKL67 product used for?
The IKL67 is an insulated aluminum service entrance compression splice, ideal for heavy-duty overhead services.
What material is the IKL67 splice constructed from?
The IKL67 splice is constructed from aluminum, ensuring high conductivity.
What is the voltage rating for IKL67 splices?
IKL67 splices provide reliable 600V insulation due to their tough stabilized-nylon sleeves.
What conductor sizes are compatible with the IKL67?
The IKL67 is compatible with 2/0 conductors for Conductor A and 3/0 conductors for Conductor B.
