ABB - Installation Products HLC3974AP9-2 - Hot Line Clamp, Aluminum, Tin-Plated, Contax Filled, Front Tap - 3/4 nut. Conductor Ranges Main 400 KCMIL, Stranded - 6, Solid 185 - 16 sq mm, TAP 4/0 Stranded - 6 Solid 95 - 16 sq mm. Main 397-5 - 6 ACSR, TAP 3/0 - 6 ACSR
ABB - Installation Products

HLC3974AP9-2

UPC: 783786530458

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 50

Multiplier: 50

*Contact for lower quantities*

Overview

The ABB HLC Series Hot Line Clamp, SKU HLC3974AP9-2, is a specialized connector designed for overhead power distribution applications. Constructed from durable aluminum and featuring a tin-plated finish for enhanced conductivity and corrosion resistance, this clamp is built for reliable performance in electrical systems. The clamp is Contax filled, ensuring a low-resistance connection and preventing oxidation at the contact points. This hot line clamp is engineered for front tap connections, utilizing a 3/4" nut for secure mounting. It accommodates a wide range of conductor sizes, making it versatile for various utility and industrial needs. The main conductor range supports stranded conductors from 400 KCMIL down to 6, and solid conductors from 185 sq mm down to 16 sq mm. For ACSR conductors, the main range is 397-5 to 6 ACSR. The tap conductor range is equally extensive, designed for stranded conductors from 4/0 down to 6, and solid conductors from 95 sq mm down to 16 sq mm. For ACSR conductors on the tap side, the range is 3/0 to 6 ACSR. Key specifications include: - Manufacturer: ABB - Installation Products - Series: HLC - Material: Aluminum - Finish: Tin-Plated - Connection Type: Hot Line Clamp - Mounting: 3/4" Nut - Main Conductor Range (Stranded): 400 KCMIL - 6 - Main Conductor Range (Solid): 185 sq mm - 16 sq mm - Main Conductor Range (ACSR): 397-5 - 6 ACSR - Tap Conductor Range (Stranded): 4/0 - 6 - Tap Conductor Range (Solid): 95 sq mm - 16 sq mm - Tap Conductor Range (ACSR): 3/0 - 6 ACSR This clamp is suitable for use where live line maintenance or connections are required, offering a secure and electrically sound method for joining conductors. The Contax filling is crucial for maintaining connection integrity over time, especially in environments prone to atmospheric contaminants. The tin plating further aids in establishing and maintaining low contact resistance, vital for efficient power transmission and minimizing energy loss. The HLC series from ABB Installation Products provides a dependable solution for critical electrical connections.
  • ABB HLC Series Hot Line Clamp for reliable electrical connections.
  • Constructed from durable aluminum with a tin-plated finish for corrosion resistance.
  • Contax filled to ensure low-resistance connections and prevent oxidation.
  • Accommodates main conductors up to 400 KCMIL stranded and tap conductors up to 4/0 stranded.
  • Features a 3/4" nut mounting type for secure installation.

Specifications

Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.7000 L
Package Weight (Metric)
0.3180 kg
Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.

IPCS7501

Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.
Copper C-Tap for 600V Applications, Wire Range Main: 2-1/0, Branch 2-12, Length 1-1/16 Inches, Height 31/32 Inch, Tin Plated, Die Code 50, Die Color Code Orange

54740TP

Copper C-Tap for 600V Applications, Wire Range Main: 2-1/0, Branch 2-12, Length 1-1/16 Inches, Height 31/32 Inch, Tin Plated, Die Code 50, Die Color Code Orange
Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 500 kcmil-6 Str, Screw Size 5/16 Hex, Length 2.71 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 2, Clear Insulation

CSB 500-2 S

Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 500 kcmil-6 Str, Screw Size 5/16 Hex, Length 2.71 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 2, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, One-Way Configuration, Wire Range 500 kcmil-6 Str, Hex Size 5/16 Inch, Length 3.99 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 3, Clear Insulation

CSB 500-3 S

Aluminum Multi-Tap Encapsulated Cable Blocks, One-Way Configuration, Wire Range 500 kcmil-6 Str, Hex Size 5/16 Inch, Length 3.99 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 3, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 350 kcmil-10 Str, Screw Size 5/16 Hex, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Outlets 2, Clear Insulation

CSB 350-2 S

Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 350 kcmil-10 Str, Screw Size 5/16 Hex, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Outlets 2, Clear Insulation
Aluminum Multi-tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 750-1/0, Screw Size 3/8 Hex, Length 3 Inches, Width 3-3/8 Inch, Height 2-1/4 Inch, Outlets 2, Quantity

CSB 750-2 S

Aluminum Multi-tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 750-1/0, Screw Size 3/8 Hex, Length 3 Inches, Width 3-3/8 Inch, Height 2-1/4 Inch, Outlets 2, Quantity
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.63 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 2, Clear Insulation

CSB 2/0-2

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.63 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 2, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 5.98 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 8, Clear Insulation

CSB 2/0-8

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 5.98 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 8, Clear Insulation
