ABB - Installation Products CSB 500-2 S - Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 500 kcmil-6 Str, Screw Size 5/16 Hex, Length 2.71 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 2, Clear Insulation
More images

ABB Installation Products CSB 500-2 S Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 500…

UPC: 783786029662


Documents & Media
BrochureManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB Installation Products CSB 500-2 S is a high-performance, encapsulated aluminum multi-tap cable block engineered for secure and reliable electrical connections in demanding industrial applications. Designed with a one-way configuration, this cable block efficiently manages multiple conductors while maintaining a compact footprint. It supports a broad wire range from 500 kcmil down to 6 AWG stranded conductors, making it suitable for heavy-duty power distribution systems. The connection system features 5/16-inch hex screw terminals, ensuring a tight and stable termination that minimizes the risk of loosening or electrical faults over time. Constructed from premium-grade aluminum, the CSB 500-2 S delivers superior electrical conductivity and exceptional resistance to corrosion, extending its service life in harsh environments. The clear PVC insulation encapsulates the block, providing both mechanical protection and dielectric strength while meeting or exceeding ANSI C119.4 standards for performance and safety. This transparent insulation also allows for quick and easy visual inspection of connections without disassembly, reducing maintenance time and improving operational reliability. With precise dimensions of 2.71 inches in length, 2.38 inches in width, and 2.75 inches in height, the CSB 500-2 S is optimized for space-efficient installations in control panels, switchgear, and junction boxes. Its two outlets enable efficient multi-point termination, streamlining wiring layouts and reducing clutter. The encapsulated design ensures protection against moisture, dust, and mechanical stress, making it ideal for use in industrial, commercial, and utility applications where durability and performance are critical. The CSB series is widely recognized for its field-proven reliability, ease of installation, and compatibility with both aluminum and copper conductors, ensuring versatility across a range of electrical systems.
  • One-way configuration multi-tap cable block
  • Accommodates wire range from 500 kcmil to 6 Str
  • Features 2 outlets with 5/16" Hex screw terminals
  • Constructed from durable aluminum for conductivity and corrosion resistance
  • Clear PVC insulation meets ANSI C119.4 specifications

Specifications

Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.4900 L
Package Weight (Metric)
0.2220 kg
Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.

IPCS7501

Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.
Copper C-Tap for 600V Applications, Wire Range Main: 2-1/0, Branch 2-12, Length 1-1/16 Inches, Height 31/32 Inch, Tin Plated, Die Code 50, Die Color Code Orange

54740TP

Copper C-Tap for 600V Applications, Wire Range Main: 2-1/0, Branch 2-12, Length 1-1/16 Inches, Height 31/32 Inch, Tin Plated, Die Code 50, Die Color Code Orange
Aluminum Multi-Tap Encapsulated Cable Blocks, One-Way Configuration, Wire Range 500 kcmil-6 Str, Hex Size 5/16 Inch, Length 3.99 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 3, Clear Insulation

CSB 500-3 S

Aluminum Multi-Tap Encapsulated Cable Blocks, One-Way Configuration, Wire Range 500 kcmil-6 Str, Hex Size 5/16 Inch, Length 3.99 Inches, Width 2.38 Inches, Height 2.75 Inches, Outlets 3, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 350 kcmil-10 Str, Screw Size 5/16 Hex, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Outlets 2, Clear Insulation

CSB 350-2 S

Aluminum Multi-Tap Encapsulated Cable Blocks - One-Way Configuration, Wire Range 350 kcmil-10 Str, Screw Size 5/16 Hex, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Outlets 2, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.63 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 2, Clear Insulation

CSB 2/0-2

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.63 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 2, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 5.98 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 8, Clear Insulation

CSB 2/0-8

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 5.98 Inches, Width 1.68 Inches, Height 1.63 Inches, Outlets 8, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 350 kcmil-10 Str, Hex Size 3/8 Inch, Length 7.31 Inches, Width 3.0 Inches, Height 2.50 Inches, Outlets 7, Clear Insulation

CSB 350-7

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 350 kcmil-10 Str, Hex Size 3/8 Inch, Length 7.31 Inches, Width 3.0 Inches, Height 2.50 Inches, Outlets 7, Clear Insulation
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 250 kcmil -6 Str, Hex Size 5/16 Inch, Length 6.98 Inches, Width 2.64 Inches, Height 2.13 Inches, Outlets 7, Clear Insulation

CSB 250-7

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 250 kcmil -6 Str, Hex Size 5/16 Inch, Length 6.98 Inches, Width 2.64 Inches, Height 2.13 Inches, Outlets 7, Clear Insulation

Frequently Asked Questions

What is the wire range for the ABB CSB 500-2 S cable block?

The ABB CSB 500-2 S cable block supports a wire range from 500 kcmil down to 6 Str.

How many outlets does the CSB 500-2 S cable block have?

The CSB 500-2 S cable block features two outlets for multiple wire connections.

What type of connection does the ABB CSB 500-2 S use?

The ABB CSB 500-2 S utilizes secure screw terminals with 5/16 Hex screws.

What are the dimensions of the ABB CSB 500-2 S cable block?

The dimensions of the ABB CSB 500-2 S are 2.71 inches in length, 2.38 inches in width, and 2.75 inches in height.

What material is the ABB CSB 500-2 S cable block made from?

The ABB CSB 500-2 S cable block is constructed from aluminum.
