Contact for Pricing
Minimum Qty: 1000
Multiplier: 1000
*Contact for lower quantities*
Overview
- Two-piece design for simplified wire insertion and crimping
- 5/16" (7.9 mm) length with 0.080" (2.00 mm) inner diameter
- Outer diameter 0.103" (2.63 mm) for secure fit in hexagonal wire ranges
- Hard bronze construction with nickel plating for corrosion resistance
- Blue color coding for quick visual identification
Specifications
Application | for Grounding, Terminating and Insulating Shielded and Coaxial Cable |
Color | Blue |
Material | Hard Bronze |
Type | Two-Piece Inner Sleeve Connector |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.0010 L |
Package Weight (Metric) | 0.0010 kg |
GSB194NP
Two Piece Inner Sleeve Connector for Hexagonal Range, Length 5/16 Inch/7.9mm, Inner Diameter .194 Inches/4.93mm, Outer Diameter .226 Inches/5.76mm, Color Blue, Hard Bronze, Nickel Plated
ISE64
Pre-Insulated Service Entry Sleeves 6 Str - 4 Sol Preinsulated service entry sleeves are used for fast and easy installation with standard tools. For combinations of aluminum-aluminum and aluminum-copper conductors. Meets the requirements of ANSI C119.4. Rated 600 Volts.
GSB250NP
Two Piece Inner Sleeve Connector for Hexagonal Range, Length 5/16 Inch/7.9mm, Inner Diameter .250 Inches/6.35mm, Outer Diameter .281 Inches/7.14mm, Color Green, Hard Bronze, Nickel PlatedGSB063NP
Two Piece Inner Sleeve Connector for Hexagonal Range, Length 5/16 Inch/7.9mm, Inner Diameter .063 Inches/1.60mm, Outer Diameter .088 Inches/2.23mm, Color Red, Hard Bronze, Nickel Plated
M7X64RRA
Replacement Housing Assembly for M4 Module - 1 Housing Receptacle with Rating for Receptacle 60A 440/480V, 1 Interior Assembly 60A, 1 Gasket, 3 Nylon Flat Washer, 1 .190-32 x .625 PHMS SS, 4 Pan Head Screws 1/4-20x3/4, 1 #10 Stainless Lock Split Washer, 1 Spirolox Ring, 1 Instruction Sheet
GSC187NP
Two Piece Outer Sleeve Connector for Hexagonal Range, Length 1/4 Inch/6.4mm, Inner Diameter .187 Inches/4.75mm, Outer Diameter .227 Inches/5.76mm, Color Orange, Soft Bronze, Nickel PlatedFrequently Asked Questions
What does the NP suffix in GSB080NP signify?
The NP suffix indicates that the terminals are nickel plated.
What are the approximate dimensions of GSB080NP?
The GSB080NP has an approximate inner diameter of .080 inches and an outer diameter of .1035 inches.
What is the maximum temperature for GSB080NP?
Tin plated parts, such as GSB080NP, should not be exposed to temperatures above 150 C.
What is the finish of GSB080NP?
The finish is electro tin plate per MIL-T-10727A Type 1, equivalent to ASTM B545 Class A.
What material is GSB080NP made from?
GSB080NP is made from commercial bronze per ASTM B36 (UNS C22000) or ASTM B140 Alloy #B.
What material is GSB080NP made from?
GSB080NP is made from commercial bronze per ASTM B36 (UNS C22000) or ASTM B140 Alloy #B.
What is the finish of GSB080NP?
The finish is electro tin plate per MIL-T-10727A Type 1, equivalent to ASTM B545 Class A.
What is the maximum temperature for GSB080NP?
Tin plated parts, such as GSB080NP, should not be exposed to temperatures above 150 C.
What are the approximate dimensions of GSB080NP?
The GSB080NP has an approximate inner diameter of .080 inches and an outer diameter of .1035 inches.
What does the NP suffix in GSB080NP signify?
The NP suffix indicates that the terminals are nickel plated.
