ABB - Installation Products KVF18-4FB-M - Vinyl Fully Insulated Female Bullet Receptacle Wire Range 22-16 Bolt Hole n/a, Package of 1000

ABB Installation Products KVF18-4FB-M Vinyl Fully Insulated Female Bullet Receptacle Wire Range 22-16 Bolt Hole n/a, Package…

UPC: 786210100081


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 1000

Multiplier: 1000

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB KVF18-4FB-M is a vinyl fully insulated female bullet receptacle designed for secure wire terminations in industrial and commercial applications. This component accommodates wire ranges from 22 to 16 AWG, providing reliable conductivity and insulation for low-voltage systems. The fully insulated design ensures protection against short circuits and accidental contact, meeting UL and CSA safety standards for electrical components. Each package contains 1000 units, optimized for bulk procurement in manufacturing, construction, or maintenance operations. The bullet-style receptacle is compatible with standard male bullet connectors, enabling quick and tool-free installations. Ideal for control panels, machinery wiring, and electrical enclosures where space efficiency and safety compliance are critical. The vinyl insulation offers resistance to moisture, chemicals, and abrasion, extending service life in harsh environments. No bolt hole is required for installation, simplifying assembly processes. This SKU is part of ABB’s Installation Products line, a trusted manufacturer in electrical infrastructure solutions.
  • Vinyl fully insulated female bullet receptacle
  • Wire range: 22-16 AWG
  • Package of 1000 units
  • No bolt hole required for installation
  • UL and CSA compliant for safety

Specifications

Connection Type
Female Bullet Receptacle
Material
Vinyl
Material
Vinyl Fully Insulated
Series
KVF18
Size
22-16
Type
Vinyl Fully Insulated Female Bullet
Voltage Rating
300 V
Wire Size
22-18 AWG
Package Dimensions (L x W x H)
7 IN x 5 IN x 4.12 IN
Package Dimensions (L x W x H)
17.78 cm x 12.7 cm x 10.4648 cm
Package Weight (Imperial)
0.0010 L
Package Weight (Metric)
0.0010 kg
