ABB - Installation Products AMT20 - AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 2/0-14 Str, Length 1.61 Inches, Width 1.50 Inches, Height 1.59 Inches, Hex Size 3/16 Inch, Black Insulation
More images

ABB Installation Products AMT20 AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 2/0-14…

UPC: 783786259205


Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 25

Multiplier: 25

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB AMT20 is a 2-port aluminum multi-tap connector designed for reliable electrical distribution. Engineered by ABB Installation Products, this connector (SKU: AMT20, UNSPSC: 39121428) is constructed from durable aluminum for excellent conductivity and longevity in wire termination applications. It features robust PVC insulation in a distinct black color, providing essential electrical protection and clear system identification. The AMT20 accommodates a broad wire range, accepting stranded conductors from 2/0 AWG down to 14 AWG, ensuring compatibility with various wiring configurations. Its compact dimensions are optimized for ease of installation, measuring 1.61 inches in length, 1.50 inches in width, and 1.59 inches in height. A 3/16 inch hex size is required for secure tightening. The Blackburn® AMT series, to which this connector belongs, is known for providing superior connections with reduced installation costs due to its ease and speed of installation. The PVC insulation is UV-resistant and designed to last the life of the connection, minimizing insulation failures and associated outage costs. This multi-port connector is ideal for splices, taps, and terminations in electrical systems.
  • 2-Port Aluminum Multi-Tap Connector
  • Wire Range: 2/0 AWG to 14 AWG Stranded
  • Durable Black PVC Insulation
  • Compact Dimensions: 1.61" L x 1.50" W x 1.59" H
  • Requires 3/16" Hex Size for Installation

Specifications

Color
Black
Connection Type
Multi-Tap Connector
Connection Type
Multi-Tap Same Side Connector
Material
Aluminum, PVC
Poles
2
Poles
2-Port
Series
AMT
Size
Length 1.61 Inches, Width 1.50 Inches, Height 1.59 Inches, Hex Size 3/16 Inch
Size
Length 1.61 Inches, Width 1.50 Inches, Height 1.59 Inches
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.2500 L
Package Weight (Metric)
0.1130 kg
Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.381 Inches, Outlets 2, Black PVC Insulation, Prefilled with Oxide Inhibitor and Capped. Includes Screws.

AMTD20142

Aluminum Multi-Tap Encapsulated Cable Blocks, Two-Way Configuration, Wire Range 2/0 kcmil-14 Str, Hex Size 3/16 Inch, Length 1.381 Inches, Outlets 2, Black PVC Insulation, Prefilled with Oxide Inhibitor and Capped. Includes Screws.
Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.

IPCS7501

Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.
AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 250 kcmil-10 Str, Length 2.12 Inches, Width 2.13 Inches, Height 2.13 Inches, Hex Size 5/16 Inch

AMT250

AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 250 kcmil-10 Str, Length 2.12 Inches, Width 2.13 Inches, Height 2.13 Inches, Hex Size 5/16 Inch
AMT Aluminum Multi-Tap Same Side Connector, 2-Port, Black PVC Insulated, Wire Range 350 kcmil-10 Str, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Hex Size 5/16 Inch

AMT350

AMT Aluminum Multi-Tap Same Side Connector, 2-Port, Black PVC Insulated, Wire Range 350 kcmil-10 Str, Length 2.22 Inches, Width 2.37 Inches, Height 2.50 Inches, Hex Size 5/16 Inch
AMT Aluminum Multi-Tap Same Side Connector, 2-Port, Black PVC Insulated, Wire Range 500 kcmil-6 Str, Length 2.71 Inches, Width 2.38 Inches, Height 2.75 Inches, Hex Size 3/8 Inch

AMT500

AMT Aluminum Multi-Tap Same Side Connector, 2-Port, Black PVC Insulated, Wire Range 500 kcmil-6 Str, Length 2.71 Inches, Width 2.38 Inches, Height 2.75 Inches, Hex Size 3/8 Inch
AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 4-14 Str, Length 1.15 Inches, Width 1.13 Inches, Height 1.25 Inches, Slotted Screw

AMTC4

AMT Aluminum Multi-Tap Same Side Connector, 2-Port, PVC Insulated, Wire Range 4-14 Str, Length 1.15 Inches, Width 1.13 Inches, Height 1.25 Inches, Slotted Screw
AMT Aluminum Multi-Tap Both Sides Connector, 3-Port, PVC Insulated, Wire Range 250MCM-10 Str

AMTD250103

AMT Aluminum Multi-Tap Both Sides Connector, 3-Port, PVC Insulated, Wire Range 250MCM-10 Str
AMT Aluminum Multi-Tap Both Sides Connector, 4-Port, PVC Insulated, Wire Range 250MCM-10 Str

AMTD250104

AMT Aluminum Multi-Tap Both Sides Connector, 4-Port, PVC Insulated, Wire Range 250MCM-10 Str

Frequently Asked Questions

What is the wire range for the ABB AMT20 connector?

The ABB AMT20 connector is designed to accommodate stranded conductors ranging from 2/0 AWG down to 14 AWG.

What type of insulation does the AMT20 connector feature?

The ABB AMT20 connector features robust PVC insulation, which is UV-resistant and black in color.

What is the required hex size for installing the AMT20 connector?

The ABB AMT20 connector requires a 3/16 inch hex size for secure tightening during installation.

What are the physical dimensions of the ABB AMT20 connector?

The ABB AMT20 connector measures 1.61 inches in length, 1.50 inches in width, and 1.59 inches in height.
