ABB Installation Products 655LINKCLRJ0300BDRG 600 Amp, 15kV, Deadbreak Cam-Op Connector Kit with Insulated Cap, Cable Insulation…
UPC: 783786651696
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 600 Amp current rating for high-capacity power applications.
- 15kV operating voltage suitable for medium-voltage systems.
- Deadbreak connector design with insulated cap for safety.
- Accommodates cable insulation diameters from 0.980" to 1.180".
- Includes aluminum compression lug for 350 kcmil stranded, 400 kcmil solid, or 185 mm² compact conductors.
Specifications
Amperage Rating | 600 A |
Application | External Visible Break, Testing, Grounding and Isolation |
Color | Black |
Conductor Range | 350 kcmil , 400 kcmil |
Connection | Compression |
Insulation | True |
Material | EPDM-Rubber |
Size | 20.50 inches from edge of Lever to Bushing Flange |
Special Features | Easily Installed or Removed by Hotstick Operation of the Cam Action Disconnect Lever |
Standard | ANSI/IEEE Standard 386 |
Temperature Rating, Maximum | 149 F |
Temperature Rating, Maximum | 65 C |
Temperature Rating, Minimum | -40 F |
Temperature Rating, Minimum | -40 C |
Type | Cam_OP Connector Kit |
Voltage Rating | 15 kV |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 27.5000 L |
Package Weight (Metric) | 12.4740 kg |

K655LR-K0300-SG1
600 Series Elbow with insulated plug, cap, stud, lug and cable adapter, 15/25KV, Cable Insulation Diameter 1.090 inch to 1.310 inch. Aluminum Compression Lug. Conductor Size kcmil Compressed/Stranded 350 or Compact/Solid 400 or mm2 Compact 185. 200ECS-G1 Jacket Seal and Grounding Kit Included.
K656CY-M0360
15-25kV 600 Series Deadbreak Separable Wye Joint Package (3-Way) with Test Point, Cable Insulation Diameter 1.370 inch to 1.630 inch. Aluminum Compression Lug. Conductor Size 650 kcmil Stranded Compressed or 750 kcmil Compacted Solid.
K656LR-L0230-S
15/25kV 600 Amp Series Deadbreak Elbow with Test Point (with Insulated Plug, Cap, Stud, Lug and Cable Adapter), Aluminum Compression Lug. Cable Insulation Diameter 1.180 inch to 1.465 inch. Conductor Size Compressed/Stranded 1 or Compact/Solid 1/0 or mm2 Compact 50. Cold-Shrinkable Jacket Seal Included.
756LR-L0300
35kV 600 Series Deadbreak Elbow with Test Point (with Insulated Plug, Cap, Stud, Lug and Cable Adapter). Aluminum Compression Lug. Cable Insulation Diameter 1.180 inch to 1.465 inch. Conductor Size kcmil Compressed Stranded 350 or Compacted Solid 400 or mmSquared Compact 185.
K656CH-M0360
600 Amp, 15/25 kV, Separable H Joint package 4-Way with Test Point, Cable Insulation Diameter 1.370 inch to 1.630 inch. Aluminum Compression Lug. Conductor Size 650 Stranded Compressed or 750 kcmil Compacted Solid.
756LR-L0230-S
35kV 600 Series Deadbreak Elbow with Test Point (with Insulated Plug, Cap, Stud, Lug and Cable Adapter). Aluminum Compression Lug. Cable Insulation Diameter 1.180 inch to 1.465 inch. Conductor Size Compressed Stranded #1 or Compacted Solid 1/0. Cold-Shrinkable Jacket Seal Included.
655CETPH0270
15kV, 600 Amp, Combo T Reducing Tap Plug with Stud, Cable Adapter, Lug and Insulated Cap Kit. Cable Insulation .850-1.050 inches. Universal Aluminum Connector Type, Connector Size 4/0 Stranded/Compressed or 250 Compact/Solid. No Test Point.
755LR-N5330
600 Amp, 35kV, 600 Series Deadbreak Elbow (with Insulated Plug, Cap, Stud, Lug and Cable Adapter). Cable Insulation Diameter 1.515 inch to 1.780 inch. Bi-Metal Compression Lug. Conductor Size AWG or kcmil, Compressed Stranded 500 /Compacted Solid 600 /mmSquared Compact 250/300.Frequently Asked Questions
What is the maximum operating voltage for this connector kit?
The ABB 655LINKCLRJ0300BDRG connector kit is designed for a maximum operating voltage of 15kV.
What is the current rating of the 655LINKCLRJ0300BDRG connector?
This ABB deadbreak connector kit has a current rating of 600 Amps.
What cable insulation diameters does this connector kit support?
The connector kit is designed to fit cable insulation diameters ranging from 0.980 inches to 1.180 inches.
What conductor sizes are compatible with the aluminum compression lug?
The aluminum compression lug is compatible with compressed stranded conductors of 350 kcmil, compacted solid conductors of 400 kcmil, and compact conductors of 185 mm².
What type of connector mechanism does this kit use?
This deadbreak connector kit features a cam-operated mechanism for secure connection.
How to Install the LINK-C Deadbreak Cam Link Operable Connector System
This guide provides step-by-step instructions for the safe and proper installation of the LINK-C 600 amp deadbreak cam link operable connector system, including mounting, wiring, and grounding procedures. Ensure all apparatus is de-energized before beginning.
Estimated time: 2h
Tools needed:
Hot stick, Torque wrench, 1-inch hex socket, Welding equipment (if studs not pre-installed), Wire strippers, Wrench/Socket set
Supplies needed:
ELASTIMOLD lubricant, 600 amp elbow, Stand-off plug (if applicable), 3/8-16 hex nuts, 3/8-16 lockwashers, 3/8-16 x 2” studs (if applicable), 600 amp bushing extender, Retainer contact, Epoxy standoff plug, Alignment bracket, LINK-C connector, #14 AWG or #12 AWG solid copper wire, Grounding connectors, HV insulated caps or connectors (if replacing shipping covers), Mating 200 amp product
- Prepare for Installation and Install 600 Amp Elbow
DANGER: Ensure all apparatus is de-energized during installation. This product must be installed only by competent personnel trained in good safety practices involving high voltage electrical equipment. Inspect all parts for damage, correct rating, and compatibility with mating parts. If supplied with protective shipping covers, remove them and replace with appropriate HV insulated caps or connectors before submerging or energizing the circuit. Install the 600 amp elbow onto the cable according to its specific installation instructions, ensuring it will align with the stand-off plug.
- Mount the Stand-Off Plug (If Applicable)
Weld three 3/8-16 x 2” studs to the equipment faceplate according to the specified dimensions. Install three hex nuts onto the studs to support the stand-off plug, ensuring it aligns with the apparatus bushing. Alternatively, use three spacers. Position the stand-off plug over the three studs, resting it on the nuts or spacers. Secure the stand-off plug by installing a lockwasher and a hex nut on each of the three studs, then tighten to 12 foot-pounds torque. Verify that the top surfaces of the apparatus bushing and the stand-off plug are in-line; readjust nuts as required.
- Install Bushing Extender and Elbow
Clean and thoroughly lubricate the apparatus bushing and both interfaces of the 600 amp bushing extender with ELASTIMOLD supplied lubricant. IMPORTANT: Bushing extender interfaces must be thoroughly lubricated to allow for proper removal of the link. Install the bushing extender onto the apparatus bushing. Insert the 600ATM operating tool into the retainer contact, engaging its internal hex broach. Insert the retainer contact into the bushing extender and thread it into the apparatus bushing using a suitable tool on the 1” hex portion of the 600ATM, torquing to 50-60 foot-pounds. Clean and thoroughly lubricate the epoxy standoff plug and both interfaces of the 600 amp elbow with ELASTIMOLD supplied lubricant. IMPORTANT: Elbow interfaces must be thoroughly lubricated to allow for proper removal of the link. Install the 600 amp elbow onto the epoxy standoff plug. Insert the 600ATM operating tool into the retainer contact, engaging its internal hex broach. Insert the retainer contact into the 600 amp elbow through the compression lug hole and thread it into the epoxy standoff plug using a suitable tool on the 1” hex portion of the 600ATM, torquing to 50-60 foot-pounds.
- Install and Align the Alignment Bracket
Remove the bushing extender clamp and elbow clamp from the alignment bracket. Position the alignment bracket on the bushing extender, measuring 2.5 inches (63.5mm) from the grounding eye. Assemble the bushing extender clamp to the alignment bracket using the supplied hardware. Torque the bolts by alternating sides until the clamp tabs are flush with each other and tight on both sides. Position the elbow within the alignment bracket, ensuring the elbow cuff is lined up evenly with the bushing extender cuff. Assemble the elbow clamp to the alignment bracket with the supplied hardware. Torque the bolts by alternating sides until the clamp tabs are flush and tight. IMPORTANT: Ensure the elbow clamp notch faces the cable entrance of the elbow.
- Insert and Secure the LINK-C Connector
Clean and thoroughly lubricate both 600 ampere interfaces of the LINK-C connector with ELASTIMOLD supplied lubricant. IMPORTANT: Interfaces must be thoroughly lubricated to allow for proper removal of the link. Align the LINK-C connector so that it is perpendicular to the switch faceplate when inserted into the bushing extender and elbow. Insert the LINK-C connector into the bushing extender and elbow, ensuring both lever arms are positioned on the inside of the alignment bracket legs. Engage the pivot pin into the slots in the alignment bracket legs. While pushing inward, use a hot stick to move the lever arms downward, engaging the roller pin and moving the LINK-C connector further inward. Continue moving the lever arms until they are perpendicular to the alignment bracket leg.
- Ground the System and Install Mating Product
Ground the elbow: Feed a #14 AWG or #12 AWG solid copper wire through the grounding eye on the elbow, twist it tight, and connect it securely to ground. Clean and lubricate the 200 amp interface on the LINK-C connector. Ground the cable: If using concentric neutral cable, twist the concentric neutral wires together and connect them to ground using an appropriate connector. If using 20MA or 21MA grounding devices, connect the ground lead from the device to ground using a suitable connector. For three-phase installations, ensure all grounds from all three phases are tied to a common ground point. Install the desired mating product on the 200 amp interface after grounding, following its specific installation instructions. Refer to applicable operating instructions for the LINK-C connector and 200 ampere mating products for operation.
