ABB - Installation Products 271-30630-5 - Long Barrel Two-Way Copper Splice, For Code and Navy Copper Cable, Splice, Silver Plated, Cable Size AWG 1 STR, Navy 75 (37), Length 2-7/8 inch, Diameter 15/32 inch, Green, Die Code 37
ABB - Installation Products

271-30630-5

UPC: 786210644479

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 20

Multiplier: 20

*Contact for lower quantities*

Overview

The ABB 271-30630-5 Long Barrel Two-Way Copper Splice is engineered for reliable connections in demanding industrial and marine applications. This splice is specifically designed for Code and Navy copper cable, including Navy 75 (37) cable types. Constructed from high-quality copper and featuring a silver-plated finish, it ensures excellent electrical conductivity and superior resistance to corrosion, crucial for maintaining signal integrity in harsh environments. The long barrel design provides ample surface area for a secure crimp, minimizing the risk of connection failure. With a precise length of 2-7/8 inches and a diameter of 15/32 inches, this splice is optimized for AWG 1 STR cable sizes. The distinct green color and the specified Die Code 37 are critical for ensuring proper tool compatibility and correct application with the intended cable specifications. Its two-way configuration facilitates efficient splicing, even in confined installation spaces. Manufactured by ABB Installation Products, the 271-30630-5 splice adheres to stringent industry standards, offering a durable and code-compliant solution for critical electrical infrastructure. Trust ABB for robust splicing components that deliver consistent performance and longevity in your most challenging projects.
  • Long barrel design for secure, reliable crimp connections
  • Silver-plated copper construction for superior conductivity and corrosion resistance
  • Optimized for AWG 1 STR and Navy 75 (37) copper cable
  • Two-way splice configuration for efficient installation
  • Green color and Die Code 37 for specific cable compatibility

Specifications

Color
Green
Conductor Range
#1 AWG
Finish
Silver Plated
Insulation
None
Material
Copper
Type
Splice Connector
Voltage Rating
35 kV
Package Dimensions (L x W x H)
3.3 IN x 2.8 IN x 2.3 IN
Package Dimensions (L x W x H)
8.382 cm x 7.112 cm x 5.842 cm
Package Weight (Imperial)
0.050 L
Package Weight (Metric)
0.023 kg
Long Barrel Two-Way Copper Connector, Cable Size 1 STR, Navy 75 (37), Length 2-7/8 Inches, Diameter 15/32 Inch, Die Color Green, Die Code 37, Tin Plated

271-30630-22

Long Barrel Two-Way Copper Connector, Cable Size 1 STR, Navy 75 (37), Length 2-7/8 Inches, Diameter 15/32 Inch, Die Color Green, Die Code 37, Tin Plated
Copper Two-Way Splice, Long Barrel, Max 35kV, Wire Size 600 kcmil, 444 kcmil Flex, Length 4.25 Inches, Silver Plated, Die Code 94, Die Color Code Green

54820SP

Copper Two-Way Splice, Long Barrel, Max 35kV, Wire Size 600 kcmil, 444 kcmil Flex, Length 4.25 Inches, Silver Plated, Die Code 94, Die Color Code Green
Copper Two-Way Splice, Long Barrel, 1 AWG, Die Set 15CA37R, Green

54008-TB

Copper Two-Way Splice, Long Barrel, 1 AWG, Die Set 15CA37R, Green
Copper Two-Way Splice, Long Barrel, Max 35kV, 400 kcmil, Length 3.75 Inches, Diameter 0.98 Inch, Silver Plated, Die Code 76, Die Color Code Blue

54816SP

Copper Two-Way Splice, Long Barrel, Max 35kV, 400 kcmil, Length 3.75 Inches, Diameter 0.98 Inch, Silver Plated, Die Code 76, Die Color Code Blue
Long Barrel Two-Way Copper Connector, For Code and Navy Copper Cable, Splice, Silver Plated, Cable Size AWG 300 mcm, Navy 300(91), Length 4-1/8 inch, Diameter 27/32 inch, White, Die Code 66 or 66H

271-30630-11

Long Barrel Two-Way Copper Connector, For Code and Navy Copper Cable, Splice, Silver Plated, Cable Size AWG 300 mcm, Navy 300(91), Length 4-1/8 inch, Diameter 27/32 inch, White, Die Code 66 or 66H
Long Barrel Two-Way Copper Connector, Cable Size AWG 3/0, Navy 150 (61), 3-1/8 inch length, 5/8 inch Diameter, Die Color Orange, Die Code 50, Silver Plated

271-30630-8

Long Barrel Two-Way Copper Connector, Cable Size AWG 3/0, Navy 150 (61), 3-1/8 inch length, 5/8 inch Diameter, Die Color Orange, Die Code 50, Silver Plated
Long Barrel Two-Way Copper Connector, Cable Size AWG 8 STR, Navy 14-23 (7), 1-3/4 inch length, 1/4 inch Diameter, Die Color Red, Die Code 21. Silver Plated

271-30630-1

Long Barrel Two-Way Copper Connector, Cable Size AWG 8 STR, Navy 14-23 (7), 1-3/4 inch length, 1/4 inch Diameter, Die Color Red, Die Code 21. Silver Plated
Long Barrel Two-Way Copper Splice, For Code and Navy Copper Cable, Splice, Silver Plated, Cable Size AWG 400 mcm, Navy 400(127), Length 4-13/16 inch, Diameter 31/32 inch, Blue, Die Code 76 or 76H

271-30630-13

Long Barrel Two-Way Copper Splice, For Code and Navy Copper Cable, Splice, Silver Plated, Cable Size AWG 400 mcm, Navy 400(127), Length 4-13/16 inch, Diameter 31/32 inch, Blue, Die Code 76 or 76H
Copper Two-Way Splice Connector, Standard Barrel, Max 35kV, Wire Size 250 kcmil, Silver Plated, Die Code 69, Die Color Code Yellow
