Overview
- Field-adjustable internal gas spring counterbalance supports loads of 30-100 lbs.
- Gas springs are set to maximum pressure (100 lb. load) and lifting force can be reduced through a sealed access cap in the top of the arm
- Lifting force cannot be increased once spring pressure is reduced
- Provides 13 in. of vertical height adjustment
- Release handle automatically locks arm in place when repositioned vertically
- Easily attach to an HMI enclosure using a 60-x-60-mm enclosure mounting pattern (enclosure must be ordered separately)
- 1.4-in. internal cable pathway maintains NEMA Type 4 and 12 enclosure rating and protects wires and cables
- Gasketed mounting surfaces at both ends of arm maintain seal integrity
- Enclosure and arm can be swiveled 320 degrees
- Mounting adapter is required with options of wall-mount, machine-top-mount and post-top-mount
Specifications
Application | Controls and Drives |
Arm Weight | 20 lb |
Arm Weight | 9.07 kg |
Color | Light Gray |
Color | Gray |
Color Code | RAL 7035 |
Depth | 89 mm |
Depth | 3.5 |
Depth | 89 |
Finish | Powder Coated |
Height | 6.72 |
Height | 171 |
Height | 171 mm |
IP Rating | IP66 |
Ip Rating | Type 4 |
Load Capacity | 14-45 kg |
Load Capacity | 30-100 lb |
Machine-Top-Mount Adapter | VLMACHINE |
Material | Aluminum |
Modification Services | Yes |
Mounting Type | Vertical Motion Pendant Arm |
Mounting Type | Wall/Machine/Post-top |
Nema Rating | Type 4 |
NEMA Rating | 12 Indoor, dust-resistant |
Post-Top-Mount Adapter | VLPOST |
Product Family | Syspend |
Protection Rating | NEMA Type 12 |
Series | VL-Motion Arm |
Series | Syspend VL-Motion Arm |
Size | 6.72x25.5x3.5 in |
Size | 6.72x25.5x3.5 |
Size | 22-inch arm |
Type | Vertical Motion Arms |
Wall-Mount Adapter | VLWALL |
Weight | 21.5 lb |
Width | 648 mm |
Width | 25.5 |
Width | 648 |
Package Dimensions (L x W x H) | 31.3 IN x 16.1 IN x 7.7 IN |
Package Dimensions (L x W x H) | 79.502 cm x 40.894 cm x 19.558 cm |
Package Weight (Imperial) | 21.400 L |
Package Weight (Metric) | 9.707 kg |
How to Install the VL22 Motion Arm
This guide provides step-by-step instructions for installing and configuring the VL22 Motion Arm for optimal performance.
Estimated time: 1h
Tools needed:
Screwdriver, 1/8 inch Allen wrench, Spanner Wrench
Supplies needed:
Mounting screws, Bronze bushings, Flange Axles
- Install the mounting end
Remove the access cap and pass the Flange Axle through the plastic bushing and the arm. Install the bronze bushing between the arm and the mount, then screw the Flange Axle into the mount.
- Adjust the swivel friction
Remove the locking set screws using a 1/8 inch Allen wrench. Loosen the inner set screw approximately 3 turns, then turn the Flange Axle using the Spanner Wrench until the desired swivel friction is achieved.
- Adjust the counterbalance force
Lower the arm and insert a #2 Phillips screwdriver into the valve actuator hole. Pump the screwdriver gently to release gas from the spring until the counterbalance force is optimal. Always wear safety glasses during this adjustment.
