nVent SFCP126 - Partial Height Swing Frames, SFCP, 197x696x60mm, Zinc Plated, Mild Steel, 12U
nVent

SFCP126

UPC: 783510527921

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance your 19" equipment mounting infrastructure with the nVent SFCP126 Partial Height Swing Frame. Engineered by nVent, a leader in electrical enclosure solutions, this robust swing frame (SKU: SFCP126) offers a practical and efficient method to expand mounting capacity and improve accessibility within your existing enclosures. Measuring 197x696x60mm and finished in a durable zinc plating over mild steel, the SFCP126 is designed for longevity and reliable performance in demanding industrial environments. This partial height swing frame is specifically designed to provide an additional 12U of mounting space for 19-inch rack-mountable equipment. Its intelligent design allows the frame to swing outwards, granting unobstructed rear access to installed components and cabling. This feature is invaluable for maintenance, troubleshooting, and upgrades, significantly reducing downtime and simplifying operational tasks. The swing mechanism is engineered for smooth operation, ensuring that even heavily loaded frames can be opened and closed with ease. The nVent SFCP126 is an ideal solution for applications where space is at a premium but additional equipment needs to be accommodated. It is commonly deployed in: * **Telecommunications:** Housing network switches, routers, and patch panels. * **Industrial Automation:** Integrating control systems, PLCs, and HMIs. * **Data Centers:** Expanding server rack density and improving cable management. * **Broadcast and A/V:** Mounting specialized audio-visual equipment. * **Utility and Energy:** Deploying monitoring and control instrumentation. Constructed from high-quality mild steel and finished with a protective zinc plating, the SFCP126 offers excellent resistance to corrosion and wear, ensuring its integrity in various environmental conditions. The 12U capacity provides substantial room for a wide array of standard 19-inch equipment, from networking devices to power distribution units. Installation is straightforward, designed to integrate seamlessly with most standard enclosure systems, further solidifying nVent's reputation for user-friendly and effective solutions. By choosing the nVent SFCP126, you are investing in a product that not only maximizes your existing enclosure space but also enhances operational efficiency through improved accessibility. Trust nVent's commitment to quality and innovation for your critical infrastructure needs. The SFCP126 is more than just a mounting accessory; it's a strategic component for optimizing your electrical and electronic equipment deployment.
  • Description: Partial height swing frame for 19”-components allowing left or right hand opening. Can be used in wall mounted, steel enclosures, and floor standing, combinable and compact, steel enclosures. Rigid S-shaped frame profile equipped with 19” hol
  • Lock: 1 double-bit 3 mm lock.
  • Material: 2 mm zinc plated steel.
  • Pack quantity: 1 swing frame with hinges.
  • Mounting requirements: Mounting in wall mounted, steel enclosures requires the SFBP transversal support in combination with the AVB. Mounting in floor standing steel combinable enclosures requires the SFBP transversal support. Adjustable in depth in combi
  • Lock: one double-bit, 3mm lock
  • Mounting requirements: mounting in wall mounted, steel enclosures requires the SFBP transversal support in combination with the AVB; mounting in floor standing steel combinable enclosures requires the SFBP transversal support; adjustable in depth in combi

Specifications

Application
Factory Automation and Process Control; Controls and Drives
Color
Unpainted
Color
Zinc Plated
Consist Of
Partial Height Swing Frames; Mounting Components and Instruction Manual
Construction
14 gauge
Depth
60 mm
Depth
2.36 in
Enclosure Material
Mild Steel
Finish
Zinc Plated
Height
800 mm
Height
31.5 in
Height
7.74 in
Load Rating
500 N
Material
Mild Steel
Material
Zinc-plated mild steel
Mounting Type
19-inch rack-mount
Package Quantity
1
Rack Height
12 U
Series
SFCP
Size
7.74 x 27.4 x 2.36 inch
Size
197x696x60mm
Thickness
2 mm
Thickness
14 ga
Type
Mounting
Type
IEC Enclosure Accessories
Weight
3.1 kg
Weight
6.9 lb
Width
27.4 in
Width
696 mm
Works With
IEC
Package Weight (Imperial)
6.900 L
Package Weight (Metric)
3.130 kg
