Overview
- 4.00 x 1.00 x 60.00 inch black steel divider strip for cable tray organization
- Designed for Quick Tray Pro systems by nVent, a leader in electrical solutions
- Prevents cable interference and simplifies maintenance in industrial and commercial applications
- Black powder-coated finish for corrosion resistance and professional aesthetics
- Requires QTPSSW3/QTPSSW3BLK Splice Washer and QTPBNWK/QTPBNWKBLK Splice Kit for secure installation
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color Code | RAL 9005 |
Modification Services | No |
Product Family | QuickTray Pro |
Thickness | 22 |
Tray Height | 102 mm |
Type | Cable Pathway |
Weight | 4 lb |
Package Dimensions (L x W x H) | 62.25 IN x 4.25 IN x 4.25 IN |
Package Dimensions (L x W x H) | 158.115 cm x 10.795 cm x 10.795 cm |
Package Weight (Imperial) | 4.000 L |
Package Weight (Metric) | 1.814 kg |
LSS18BLKP
Ladder Rack, Straight Section, Bulletin DCR (Ladder Tray - Ladder Tray and Fittiings - 18"), Size/Dims: 18.00x120.00, Material: Steel, Finish: BlackHow to Install and Configure QUICK TRAY PRO Cable Tray
This guide provides comprehensive instructions for cutting, bending, connecting, and supporting QUICK TRAY PRO cable tray sections to create custom cable management pathways.
Estimated time: 2h
Tools needed:
Hoffman Side Action Bolt Cutter
Supplies needed:
QUICK TRAY PRO Cable Tray Sections, Splice Kits (QTPBNWK/QTPBNWKBLK), Splice Washers (QTPSSW3/QTPSSW3BLK), Universal Splice Bars (QTPUS10/QTPUS10BLK), T-Connection or 90-degree Splice Bars (QTP90TKIT/QTP90TKITBLK), Cable Tray Supports
- Plan Cable Tray Layout
Determine the required cable tray configuration, including straight runs, bends, and junctions. Review the specific cutting patterns provided in the full manual for your tray size and desired modifications (e.g., 90-degree bends, elbows, tees) before proceeding with any cuts.
- Cut Cable Tray Sections
Use the Hoffman side action bolt cutter to make precise cuts. First, cut the top side wire at an angle away from the new end, resting the jaws on the cradle wire. Repeat this process for all remaining side wires. Then, turn the tray over and cut the bottom wires from the underside, also at an angle and resting on the cradle wire. Ensure each cut is clean to minimize sharp edges and prevent corrosion.
- Form Bends or Junctions
For 90-degree bends, cut the specified side and bottom wires at the bend location according to the tray width's cutting pattern. Smoothly bend the tray until the inside edges meet. Secure the bend using Splice Kits and Splice Washers. For other modifications like elbows, tees, or width reductions, follow the specific cutting and bending instructions in the manual, utilizing appropriate Splice Kits, Splice Washers, and Splice Bars (e.g., Universal Splice Bars, T-Connection Splice Bars).
- Connect Tray Sections
Join straight or modified tray sections using Splice Kits (three-piece staked bolt, washer, and nut) and Splice Washers. Ensure all connections are secure. For added support and stability, especially on tray sides, incorporate Universal Splice Bars as needed, cutting them to fit with bolt cutters if necessary.
- Support the Cable Tray
Install cable tray supports for straight sections at 6-foot (1.5m) centers. Position supports within 24 inches (610mm) of any splice on straight sections, ensuring the span between supports does not exceed the length of the tray. Add additional supports around bends and where the cable tray level changes to maintain stability and proper load distribution.
