Overview
- The Cable Runway Elevation Kit elevates ladder rack 3 or 6 inches (76 or 152 mm) above the rack-to-ladder mounting plate
- This kit can be used on any width ladder rack
- The kit includes two brackets and all mounting hardware necessary
- Compatible with any width of nVent ladder rack.
- Enhances airflow, accessibility, and vertical space utilization.
Specifications
Application | Networking, Storage and Data Center |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Finish | Black |
Height | 12 in |
Material | Steel |
Modification Services | Yes |
Mounting Type | Bracket Mounting |
Size | 12.00 in (304.8 mm) |
Size | 12.00 inches |
Thickness | 3.04 mm |
Thickness | 11 ga |
Type | Cable Pathway |
Weight | 1.8 lb |
Package Dimensions (L x W x H) | 18 IN x 4 IN x 1.5 IN |
Package Dimensions (L x W x H) | 45.72 cm x 10.16 cm x 3.81 cm |
Package Weight (Imperial) | 1.800 L |
Package Weight (Metric) | 0.817 kg |
How to Install the LEK12B Cable Runway Ladder Rack System
This guide provides instructions for installing the LEK12B cable runway ladder rack system. Please refer to the product's nameplate or datasheet for specific ratings, dimensions, voltages, strip lengths, torques, or ranges.
Estimated time: 1h
Tools needed:
Measuring tape, Level, Drill, Wrench set, Safety glasses
Supplies needed:
Mounting hardware (e.g., bolts, nuts, washers), Cable runway sections, Support brackets, Splice kits
- Plan the Layout
Determine the desired path for the cable runway. Measure the total length required and identify mounting points. Ensure the path avoids obstructions and meets all installation requirements. Consult the datasheet for any specific clearance or load-bearing guidelines.
- Install Support Structures
Install the necessary support structures (e.g., ceiling supports, wall brackets, triangle supports) at the planned mounting points. Use appropriate hardware for the mounting surface. Ensure all supports are level and securely fastened. Refer to the specific support kit instructions for detailed mounting procedures.
- Assemble Runway Sections
Connect individual cable runway sections using the appropriate splice kits (e.g., Butt Splice Kit, Junction Splice Kit). Follow the instructions provided with the splice kit to ensure a secure and continuous runway. Ensure all connections are tight and aligned.
- Mount the Cable Runway
Attach the assembled cable runway sections to the installed support structures. Use the provided hardware to secure the runway to the supports. Ensure the runway is level and stable throughout its length.
- Install Accessories (if applicable)
Install any necessary accessories such as radius drops, end caps, or termination kits according to their specific instructions. These components help manage cable bends and protect the runway ends.
- Final Inspection and Cable Loading
Perform a final inspection of the entire installation to ensure all components are securely fastened and the runway is properly aligned. Once confirmed, cables can be carefully loaded onto the runway. Do not exceed the weight capacity specified on the product's nameplate or datasheet.
