Contact for Pricing
Overview
- nVent QTPBNWK Splice Kit for nVent Quick Tray Pro systems
- Durable steel construction with zinc plating
- Includes staked bolt, washer, and nut for vibration resistance
- Pkg. Qty.: 50 kits
- Designed for industrial, commercial, and energy sectors
Specifications
Application | Networking, Storage and Data Center |
Color | Unpainted |
Color | Light Gray |
Material | Steel |
Modification Services | No |
Product Family | QuickTray Pro |
Series | Quick Tray Pro |
Size | 2.00x4.00x2.00 inches |
Thickness | 0.19 in |
Type | Cable Pathway |
Weight | 3.3 lb |
Package Dimensions (L x W x H) | 5.6 IN x 4 IN x 3.1 IN |
Package Dimensions (L x W x H) | 14.224 cm x 10.16 cm x 7.874 cm |
Package Weight (Imperial) | 3.300 L |
Package Weight (Metric) | 1.497 kg |
How to Connect QUICK TRAY PRO Cable Tray Sections Using the QTPBNWK Splice Kit
This guide provides step-by-step instructions for connecting QUICK TRAY PRO cable tray sections, including straight runs, bends, elbows, and tees, using the QTPBNWK Splice Kit and QTPSSW3 Splice Washers.
Estimated time: 30m
Tools needed:
Hoffman Side Action Bolt Cutter (QTPBC), Wrench or Socket Set
Supplies needed:
QTPBNWK Splice Kit, QTPSSW3 Splice Washer, QUICK TRAY PRO Cable Tray sections, Universal Splice Bars (QTPUS10) or T-Connection Splice Bars (QTP90TKIT) as needed
- Prepare Cable Tray Sections for Connection
Determine the required configuration (e.g., straight run, 90-degree bend, elbow, tee). Use the Hoffman side action bolt cutter to cut the QUICK TRAY PRO Cable Tray wires according to the specific cutting patterns provided in the manual for your desired connection. Always rest the cutting jaws on the cradle wire and cut at an angle away from the new end. Make one clean cut to minimize sharp edges and protect against corrosion. Exercise caution to avoid sharp edges.
- Align Cable Tray Sections
Position the prepared cable tray sections to form the desired connection. For bends, smoothly bend the tray until the inside edges meet. For elbows and tees, align the cut wires of the two trays at the desired angle. Ensure all sections are properly oriented and ready for fastening.
- Secure Connection with Splice Kits and Washers
Fasten the aligned tray sections using the QTPBNWK Splice Kits and QTPSSW3 Splice Washers. For most connections (e.g., 90-degree bends, elbows, 90-degree tees), use two QTPBNWK Splice Kits and QTPSSW3 Splice Washers per joint, as indicated for the tray width. For adjustable elbows, use one QTPBNWK Splice Kit and one QTPSSW3 Splice Washer, centered over two tray bottom wires. For Y-junction tees, connect side wires and then use QTPBNWK Splice Kits and QTPSSW3 Splice Washers, with the quantity varying based on tray width (one for 4-6 inch, two for 8-12 inch, three for 16 inch and wider trays). Tighten all bolts securely.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
