Overview
- Front and rear access to 19-inch rack equipment provided by three-part design: door, center section and wall section
- Solid door provides complete physical and visual protection
- Integral top solar/drip shield
- Two thermostatically controlled, long-life, high-performance fans mounted into top
- Window door, made of .25-inch scratch-resistant safety glass and mechanically fastened, provides visual monitoring of internal equipment while maintaining equipment protection
- All seams are fully welded and ground smooth
- Perforated, vented base with internal, expanded metal, serviceable filter
- Door, center section and wall section are provided with ground studs to facilitate proper bonding and grounding of the cabinet
- Premium seamless, foam-in-place gasket prevents contaminants from entering the cabinet
- Key-locking wing knob provides access control to the cabinet; two keys are included with each cabinet
Specifications
Additional Rack Angles | PTRA36T or PTRA36S |
Application | Controls and Drives;Networking, Storage and Data Center |
Application | Networking, Storage and Data Center; Controls and Drives |
Body Thickness | 1.9 mm |
Body Thickness | 14 ga |
Body Thickness | 16 ga |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 24.02 |
Depth | 610 |
Depth | 24.02 in |
Depth | 610 mm |
Door Thickness | 16 ga |
Door Thickness | 14 ga |
Door Thickness | 1.52 mm |
Finish | Lt Gray;Powder Coating |
Finish | Powder Coated |
Height | 36.3 in |
Height | 36.3 |
Height | 922 |
Height | 922 mm |
IP Rating | IP30 |
Ip Rating | Type 3R |
Material | Mild Steel;Steel |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Wall Mounting |
NEMA Rating | Type 1 |
NEMA Rating | 1 Indoor, electrical protection |
NEMA Rating | 1 |
Optional Steel Panel | CP3220 |
Optional Wood Panel | CP3220W |
Product Family | ProTek |
Rack Units | 19 |
Series | ProTek Double-Hinge Fan Package |
Size | 36.30x23.62x24.02 |
Type | Data Networking Wall Mounted Cabinets |
Type Number | Type 1 |
Weight | 160 lb |
Width | 526 |
Width | 23.62 in |
Width | 600 mm |
Package Dimensions (L x W x H) | 45 IN x 30 IN x 28.75 IN |
Package Dimensions (L x W x H) | 114.3 cm x 76.2 cm x 73.025 cm |
Package Weight (Imperial) | 160.000 L |
Package Weight (Metric) | 72.576 kg |
