nVent PSC20610B12 - ProLine V/D Server Cabinet Type 12, 2000x600x1000mm, Black, Steel

nVent PSC20610B12 ProLine V/D Server Cabinet Type 12, 2000x600x1000mm, Black, Steel

UPC: 783510149277

Documents & Media
Installation Instructions

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The nVent ProLine V/D Server Cabinet, SKU PSC20610B12, is engineered for superior protection and operational reliability in demanding industrial environments. This robust Type 12 enclosure, constructed from durable black steel, measures 2000mm in height, 600mm in width, and 1000mm in depth, providing ample space for voice/data equipment and servers. Its primary design objective is to safeguard sensitive electronics from the ingress of dust, dirt, oil, and water, making it an ideal solution for applications where environmental contaminants are a significant concern. Manufactured by nVent, a globally recognized leader in electrical enclosure solutions, the ProLine series embodies a commitment to quality and performance. This specific cabinet is built to meet stringent Type 12 NEMA standards, ensuring a high level of protection against falling dirt and dripping or light splashing liquids. The sealed construction is paramount for maintaining the integrity of internal components, preventing premature failure and extending the lifespan of your critical IT infrastructure. This is particularly crucial in sectors such as manufacturing, food and beverage processing, and outdoor installations where harsh conditions are the norm. Beyond its protective capabilities, the ProLine V/D Server Cabinet offers significant flexibility for thermal management. Recognizing that heat is a major enemy of electronic equipment, nVent has incorporated optional cutouts designed to facilitate the integration of air conditioning units. This feature allows for precise climate control within the cabinet, ensuring that servers and voice/data equipment operate within their optimal temperature ranges, even in hot or poorly ventilated areas. Effective thermal management is not just about preventing shutdowns; it's about maintaining peak performance and preventing long-term degradation of components. Key features and benefits include: * **Robust Construction:** Heavy-duty black steel provides exceptional durability and resistance to physical impact. * **Type 12 Protection:** Sealed design guards against dust, dirt, oil, and dripping/splashing liquids, ensuring component safety. * **Generous Dimensions:** 2000x600x1000mm offers substantial internal volume for extensive equipment. * **Thermal Management Options:** Provisions for air conditioning units to maintain optimal operating temperatures. * **Manufacturer Reliability:** Backed by nVent's extensive expertise and reputation in industrial enclosure solutions. * **Versatile Applications:** Suitable for manufacturing plants, data centers, telecommunications, and other challenging environments. When selecting an enclosure for critical voice/data equipment and servers, the choice of manufacturer and product line is paramount. nVent's ProLine series, with its focus on environmental protection and thermal control, offers a dependable and effective solution. The PSC20610B12 model, in particular, represents a significant investment in the longevity and performance of your IT assets, ensuring uninterrupted operation even in the most demanding industrial settings. Its US origin further underscores a commitment to quality manufacturing standards. Professionals can rely on this cabinet for secure, protected, and climate-controlled housing for their essential network and server hardware.
  • Fully gasketed to keep contaminants away from equipment, reducing maintenance costs
  • Three-point locking handles on all doors provide easy but controlled access; two keys included
  • Rack angles are infinitely adjustable from front to rear for positioning flexibility
  • Mobile base provides easy placement of cabinet
  • Levelers and anti-tip bracket secure cabinet to the floor
  • AC package has cutout for easy in-the-field installation of SpectraCool G-Series Air Conditioner (shipped separately)
  • Mobile base includes casters, levelers and gland plate
  • Gland plate allows easy routing of cable
  • Front window door made of 16 or 14 gauge steel with safety glass window
  • Solid 16 or 14 gauge steel back door

Specifications

Application
Networking, Storage and Data Center
Cabinet Package Type
Server, Standard
Color
Jet Black
Color
Black
Color Code
RAL 9005
Depth
999 mm
Depth
39.34 in
Depth
999
Finish
Powder Coated
Finish
Powder Coating;Steel/Black
Height
82.1 in
Height
2,085 mm
Height
2,085
Hole Type
Square
Material
Mild Steel
Modification Services
Yes
NEMA Rating
12 Indoor, dust-resistant
NEMA Rating
12
Product Family
ProLine
Protection Rating
NEMA Type 12
Rack Angle
PRA1920THL1
Rack Units
42 U
Style
Server Cabinet, Standard
Thickness
1.9 mm
Thickness
1.9
Thickness
14 ga
Type
Data Networking Freestanding Cabinets
Weight
448 lb
Width
608 mm
Width
23.94 in
Width
608
Package Dimensions (L x W x H)
46.5 IN x 30.75 IN x 87.75 IN
Package Dimensions (L x W x H)
118.11 cm x 78.105 cm x 222.885 cm
Package Weight (Imperial)
448.000 L
Package Weight (Metric)
203.213 kg
Power supply for DIN-rail

PS-60

Power supply for DIN-rail
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.

UTP6AL1MBU

The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Symmetrical DIN rail 2m 35x15x1,5 steel z-b

50000043

Symmetrical DIN rail 2m 35x15x1,5 steel z-b
5-port Ethernet Switch

SDI-550

5-port Ethernet Switch
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.

CPP24FMWBLY

The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included

3085

Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .

ST4803PDGM

Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
6U PERF PANEL

PPFS19010BK

6U PERF PANEL
Fiber cable ODC to SC duplex - 670mm

Fiber cable ODC SC Duplex 670mm

Fiber cable ODC to SC duplex - 670mm
Cable Manager, fits 19-inch open rack, Black, Steel

ECK19H

Cable Manager, fits 19-inch open rack, Black, Steel
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL

F62ERLNSNSNM002

OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.

CESUM3-C15

Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.

How to Safely Handle and Install Large Hoffman Enclosures

This guide provides instructions for safely handling and installing large Hoffman enclosures, emphasizing precautions to prevent injury and equipment damage.

Estimated time: 1h

Tools needed:

Forklift, Overhead lifting device (e.g., crane), Slings with load-rated hooks or shackles, ROLL•A•LIFT™ or similar device (for some models)

Supplies needed:

3000 lb.-rated chain or strap (for securing to forklift mast), Rigging equipment (for overhead lifting)

  1. Read Safe Handling Requirements

    Before moving or installing the enclosure, thoroughly read and understand the 'Large Enclosure Safe Handling Requirements' document that accompanied the enclosure. Ensure the route is clear of obstructions and all personnel are at a safe distance.

  2. Prepare for Movement

    Ensure the enclosure is stabilized before removing any strapping. Verify that the lifting equipment (forklift or overhead device) has a sufficient load rating for the enclosure's weight and size. Only trained and authorized personnel should operate the lifting equipment.

  3. Position Forklift Forks

    For forklift handling, spread the forks to the maximum distance or as dictated by the skid width. Enter the skid from the rear (Side A) of the enclosure. Position the enclosure carefully on the forks, keeping the load against the carriage/mast and tilting the load backward towards the mast.

  4. Secure Enclosure to Forklift

    If using a forklift, secure the enclosure to the forklift mast before moving. Insert a 3000 lb.-rated chain or strap through the eye bolts provided on top of the enclosure and fasten it securely to the forklift mast assembly. Ensure sufficient tension to prevent tipping.

  5. Lift and Transport Enclosure

    Lift the enclosure a minimum distance so the skid is just clear of the floor. Start and stop the forklift slowly and gradually, avoiding jerky movements. Drive slowly with the forks carried as low to the ground as possible. Never attempt to move more than one enclosure at a time.

  6. End Loading/Unloading (if applicable)

    For end loading/unloading on trailers, spread forks to match pallet end slot openings and enter from the narrow side (C or D). Secure the enclosure to the forklift mast using chains or straps. Tilt the mast to take weight off the opposite end and slide/push the enclosure as required. Do not use chains or straps to lift the enclosure.

  7. Overhead Lifting (if applicable)

    If using overhead lifting, attach rigging to the eye bolts, ensuring the angle between lifting cables and the vertical does not exceed 45 degrees. Use slings with adequate load-rated hooks or shackles. Ensure the load rating of the lifting device and rigging is sufficient. Do not use ropes or cables through eye bolts.

  8. Final Placement

    Once the enclosure is at its final location, carefully position it. Ensure it is stable and permanently installed according to any specific product instructions not covered in this general handling guide. Refer to the nameplate or datasheet for model-specific details.
