Contact for Pricing
Overview
- Rack angles are sold in pairs that are RU marked on all sides
- One side is tapped 10-32 while the other side is square hole (.375 x .375 inch)
- Both sides are spaced per EIA universal standard
- Rack angles may be assembled in either tapped or square-hole configuration
- Rack angles and mounting brackets are formed from heavy gauge steel
- All hardware and brackets are included for assembly into cabinet
Specifications
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment |
Application | Datacom and Telecom Equipment;Networking, Storage and Data Center |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Depth | 27.56 |
Depth | 700 |
Depth | 700 mm |
Finish | Powder Coated |
Finish | Powder Coating |
Fits Cabinet | 2100x700 in |
Fits Height | 2000 mm mm |
Height | 2,100 mm |
Height | 82.68 |
Height | 2,100 |
Material | Steel |
Material | Mild Steel |
Mounting | 19-in. |
Mounting Type | Rack Mounting |
Product Family | ProLine S1 |
Rack Spacing | 19- or 23-in. |
Rack Units | 45 |
Rack Width | 19 in |
Series | ProLine S1 |
Size | 2100x700 mm |
Thickness | 12 Gauge |
Thickness | 12 |
Thickness | 2.66 |
Thickness | 2.66 mm |
Type | Networking Accessories |
Weight | 25 lb |
Width | 700 mm |
Width | 27.56 |
Width | 700 |
Package Dimensions (L x W x H) | 86.5 IN x 6.5 IN x 6.5 IN |
Package Dimensions (L x W x H) | 219.71 cm x 16.51 cm x 16.51 cm |
Package Weight (Imperial) | 25.000 L |
Package Weight (Metric) | 11.340 kg |
