Overview
- All doors have toolless hinges that allow the doors to easily be removed or reversed in the field
- All doors have ergonomic opening, keylocking handles
- Easy-to-remove side panels with keylocking latch
- Front and rear doors are fully perforated to allow for maximum air flow
- Top accepts additional cooling fans (2 x 6-in. fans) with integral finger guard prefabricated in place
- Top has sliding gland plate to accommodate large cable egress capacity
- Combination foot and adjustable leveler in each cabinet corner
- Open base for easy cable entrance
- Rack angles are fully adjustable front to rear, easily converting between tapped or square configurations
- Rack angles able to mount off-centered on 700 and 800mm wide models
Specifications
Application | Datacom and Telecom Equipment;Networking, Storage and Data Center |
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment |
Cabinet Type | Communication |
Cable Entry | Yes |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 31.43 |
Depth | 798 |
Depth | 31.43 in |
Depth | 798 mm |
Finish | Powder Coating |
Finish | Powder Coated |
Frame | Yes |
Height | 2,163 mm |
Height | 85.14 |
Height | 2,163 |
Material | Mild Steel |
Material | Steel |
Mounting | Floor Stand |
Mounting Type | Floor-standing with casters and levelers |
NEMA Rating | NEMA Type 1 |
NEMA Rating | 1 |
Product Family | ProLine S1 |
Protection Rating | NEMA Type 1 |
Rack Angle | PS1RA217 |
Rack Spacing | 19- or 23-in. |
Rack Units | 45 |
Rack Width | 19 in |
Series | ProLine S1 |
Size | 2150x700x800mm |
Thickness | 16 Gauge |
Thickness | 1.52 mm |
Thickness | 16 |
Thickness | 1.52 |
Type | Data Networking Freestanding Cabinets |
Weight | 372 lb |
Width | 708 mm |
Width | 27.87 |
Width | 708 |
Package Dimensions (L x W x H) | 38 IN x 37.5 IN x 94 IN |
Package Dimensions (L x W x H) | 96.52 cm x 95.25 cm x 238.76 cm |
Package Weight (Imperial) | 372.000 L |
Package Weight (Metric) | 168.739 kg |
