Contact for Pricing
Overview
- Lifting eyes can be used to attach the solid top, in place of the included hardware
- Seamless polyurethane gasket (UL component recognized) provides a water-tight, dust-tight seal against moisture and contaminants
- Additional support provisions need to be made to support top mount air conditioners or other top mount accessories
- Includes four M12 hex bolts for installation
- Solid Tops are finished with paint over plated surfaces
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color | Painted |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 1600x800 mm |
Material | Mild Steel |
Product Family | ProLine |
Series | ProLine G2 |
Size | 1600x800mm |
Thickness | 16 ga |
Thickness | 1.52 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 41 lb |
Package Dimensions (L x W x H) | 67 IN x 34 IN x 2.25 IN |
Package Dimensions (L x W x H) | 170.18 cm x 86.36 cm x 5.715 cm |
Package Weight (Imperial) | 41.000 L |
Package Weight (Metric) | 18.598 kg |
