Overview
- Accommodates five loading options: vertical front, vertical side, vertical rear, horizontal front (frame over subpanel), horizontal rear (subpanel lowered into frame)
- High space efficiency ratio (HxW of subpanel)/(HxW of frame) of 84 percent
- Mounting subpanel is securely fastened at the top and bottom of the enclosure; subpanels less than 1200mm wide include four sets of EZ-Load Glide Blocks, four BV-M6 fasteners (block to frame) and four M12 Hex Bolts (subpanel to block); Subpanels 1200mm an
- Subpanels greater than 1000mm wide are 11 gauge (3.0 mm) mild steel, while subpanels 100mm or narrower are 12 gauge (2.5mm); conductive or white painted finish available
- Subpanels can be mounted at any depth in 25-mm increments (front to back); accommodates back-to-back and fully recessed rear positions
- Side-mount panels must be used for the sides of the enclosure; they can be installed on the interior sides of frames
- Optional panel support bracket available for applications requiring more support in the center of the subpanel; this is required if the enclosure will be tipped in transit or if the panel is not located at the bottom of the enclosure on the glide blocks
- Panels can be installed in the rearmost position, or positioned so joined enclosures provide a continuous mounting surface without requiring joining panels
- High space efficiency ratio (HxW of subpanel)/(HxW of frame) of 84 percent
- Side-mount panels must be used for the sides of the enclosure; they can be installed on the interior sides of frames
Specifications
Application | Controls and Drives; Power Distribution |
Color | White |
Finish | Powder Coated |
Fits Frame | 1600x1000 mm |
Material | Mild Steel |
Mounting Type | EZ-Load Mounting System |
Product Family | ProLine |
Series | ProLine G2 |
Size | 1600x1000 mm |
Thickness | 12 ga |
Thickness | 2.66 mm |
Type | Painted |
Weight | 115 lb |
Package Dimensions (L x W x H) | 59.3 IN x 44.4 IN x 2 IN |
Package Dimensions (L x W x H) | 150.622 cm x 112.776 cm x 5.08 cm |
Package Weight (Imperial) | 115.000 L |
Package Weight (Metric) | 52.164 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
How to Install the P2KDR18186 Controller
This guide provides step-by-step instructions for installing and configuring the P2KDR18186 Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the P2KDR18186 controller to the designated mounting surface using the provided mounting screws. Ensure the controller is level and firmly attached.
- Connect the power supply
Using wire strippers, prepare the power supply wires and connect them to the appropriate terminals on the controller. Ensure the connections are tight and secure.
- Verify connections
Use a multimeter to check the voltage at the power terminals of the controller. Ensure the voltage is within the specified range before powering on the device.
- Power on the controller
Turn on the power supply to the controller and observe the status indicators to ensure the device is functioning correctly.
- Configure the controller settings
Access the controller's configuration interface and input the necessary parameters as per your application requirements.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate operation of the controller.
