Overview
- 12-gauge (2.5 mm) roll-formed steel with welded corners, and hybrid frame profile for superior performance under load
- Frame features a 25-mm DIN standard, alternating rectangular and round hole pattern
- Enclosures with a width of 1200mm or less have a single-piece rear cover, and can accommodate a fully-recessed mounting subpanel; enclosures with a width of greater than 1200mm have two rear covers that affix to a removable center upright/vertical combina
- Gasket is seamless polyurethane providing a water-tight, dust-tight seal against moisture and contaminants; UL component recognized, CSA compliant
- Door bar system present on all doors (including window doors)
- Single/primary door includes Smooth Glide Latching System, 3-point roller latch system with timed latch engagement, for enclosures greater than or equal to 1000 mm in height; system ensures a solid and repeatable seal with a low closure force
- 2-door enclosures include overlapping double doors to provide full-width open front, with a secondary door that latches with two levers
- Reversible hinging on single doors (default left hinge), and on overlapping double doors (default right door primary door)
- Two grounding studs present on each door
- Low-Profile Flush Swing Handle with key lock on standard versions; double bit lock on 'E' versions; other handle options available (sold separately)
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 19.88 |
Depth | 505 |
Door Quantity | 2 |
Finish | Powder Coated |
Height | 78.82 |
Height | 2,002 |
Material | Mild Steel |
Material | Steel |
Max Rack Mount Unit | 42 |
Max Subpanel Size | 75.0 x 36.5 in |
Max Subpanel Size | 1906 x 928 mm |
Mounting Type | Modular Enclosure with Full Mounting Subpanel |
Nema Rating | Type 12 |
Product Family | ProLine |
Series | ProLine G2 |
Size | 2000x1000x500 |
Type | Mild Steel Modular Industrial Enclosures |
Weight | 430 lb |
Width | 39.67 |
Width | 1,008 |
Package Dimensions (L x W x H) | 47 IN x 26.5 IN x 88 IN |
Package Dimensions (L x W x H) | 119.38 cm x 67.31 cm x 223.52 cm |
Package Weight (Imperial) | 430.000 L |
Package Weight (Metric) | 195.048 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
Frequently Asked Questions
What are the key features of the ProLine G2 enclosure?
The ProLine G2 has a 15% higher load rating than competitors, can hold over 45% more weight on the subpanel, and offers more than 400 standard industrial packages. It features a comprehensive set of standard components that can be used to create custom enclosure solutions.
What types of enclosure configurations are available?
ProLine G2 offers multiple frame heights from 600mm to 2200mm, widths from 400mm to 1200mm, and depths from 400mm to 1000mm. Type 12 and Type 3R ratings are available, with options for EMC frames and various external components.
What safety and security features are included?
Safety features include mechanical and electrical interlocks, barrier panels, disconnect doors, tamperproof hardware kits, anti-tip brackets, and wall-mount brackets. The Sequestr package helps mitigate arc flash occurrences by isolating incoming power.
What mounting options are available for internal components?
Internal mounting options include full subpanels, partial subpanels, swing-out subpanels, side-mount subpanels, grid straps, 19-inch rack angles, and adjustable rack-mounting rails. Components can be mounted vertically, horizontally, and at various depths.
What cable management solutions are provided?
Cable management options include cable entry cabinets, top mounting modules, vertical tie-down cable managers, basket trays, power strip brackets, wire management rails, D-ring cable managers, and VELCRO cable wraps.
