Overview
- Smooth Glide latching system – for a smooth, reliable and repeatable door close over enclosure lifetime
- Low-profile Swing Handle with key lock; other options available
- Seamless polyurethane gasket (UL Component Recognized) provides a water-tight, dust-tight seal against moisture and contaminants
- Single doors available for frames up to 1000 mm wide
- Overlapping double doors available for frames 800 mm wide and greater
- Door bar system on all doors
- Timed latch engagement to ensure top and bottom of door catch reliably
- Durable, double-flanged latch rod and three Delrin® rollers to prevent metal-on-metal grinding
- 3-point latch system for doors ≥ 1000 mm in height
- Key lock handle standard; other options available
Specifications
Application | Controls and Drives; Power Distribution |
Color | Light Gray |
Color | Painted |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 1800 x 1200 mm |
Material | Mild Steel |
Material | Solid Doors |
Product Family | ProLine |
Series | ProLine G2 |
Size | 1800x1200mm |
Thickness | 14 ga |
Thickness | 1.9 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 110 lb |
Package Dimensions (L x W x H) | 73 IN x 27 IN x 7 IN |
Package Dimensions (L x W x H) | 185.42 cm x 68.58 cm x 17.78 cm |
Package Weight (Imperial) | 110.000 L |
Package Weight (Metric) | 49.896 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the P2DO1812 Controller
This guide provides step-by-step instructions for installing and configuring the P2DO1812 Controller for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Mount the controller
Secure the P2DO1812 Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Using wire connectors, connect the power supply wires to the designated terminals on the controller. Ensure correct polarity to avoid damage.
- Verify connections
Use a multimeter to check the voltage at the power terminals. Ensure the voltage matches the specifications outlined in the controller's manual.
- Configure the controller settings
Access the controller's configuration interface and set the desired parameters according to your application requirements.
- Calibrate the controller
Follow the calibration procedure in the manual to ensure accurate readings and performance. Adjust settings as necessary based on the calibration results.
