Contact for Pricing
Overview
- Narrow design fits 12-in (300-mm) deep cabinets
- 2000 BTU cooling capacity
- 460V AC power input
- Indoor/Outdoor rated (UL/cUL Type 12, 3R, 4; CE IP56)
- Durable light gray steel construction (RAL 7035)
- Narrow design accommodates 12-inch deep cabinets
- R407C, R513A or R134a refrigerants
- Models for 115, 230 and 400/460 3-phase VAC power input
- Outdoor model operating temperature range from -40 F/-40 C to 131 F/55 C (125 F/52 C on N28 Series)
- Reliable mechanical thermostat on enclosure side of the unit; indoor air conditioner models include digital display on ambient side
Specifications
Ambient Temperature | -40-131 °F |
Ambient Temperature | 40 Deg C |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Application | Controls and Drives; Power Distribution; Corrosive Environments |
Color | Gray |
Color | Light Gray |
Color Code | RAL 7035 |
Corrosion Resistant | No |
Depth | 9.9 in |
Depth | 251 mm |
Finish | Powder Coated |
Height | 639 mm |
Height | 25.17 in |
Material | Steel |
Material | Mild Steel |
Max Current | 1.9 A |
Mechanical Advantage | Galvanized Sheet Metal Standard (Optional: Stainless Steel) |
Mounting | Side wall |
Mounting Type | Wall/Floor Mount |
Mounting Type | Wall-mount, Floor-mount |
NEMA Rating | 12 Indoor, dust-resistant |
Nominal Capacity Btu/h | 2,000 Btu/h |
Nominal Capacity Watts | 586 W |
Nominal Voltage | 460 V |
Number Of Phases | 1 |
Operating Temperature | -40-131 |
Operating Temperature | -40-55 |
Operating Temperature | -40-55 °C |
Outdoor Installation | Yes |
Product Family | SpectraCool |
Protection Rating | NEMA Type 12 |
Refrigerant | R513A |
Remote Access Control | Yes |
Series | SpectraCool Narrow |
Size | 12-inch (300-mm) deep |
Thickness | 1.21 mm |
Thickness | 18 ga |
Thickness | 51.40mm (2.024") |
Type | Air Conditioners |
Voltage AC | 400-460 V |
Voltage Rating | 460 VAC |
Voltage Rating | 460 V |
Weight | 25 kg |
Weight | 2 lb |
Width | 254 mm |
Width | 10 IN |
Package Dimensions (L x W x H) | 14.5 IN x 11.75 IN x 34.25 IN |
Package Dimensions (L x W x H) | 36.83 cm x 29.845 cm x 86.995 cm |
Package Weight (Imperial) | 79.000 L |
Package Weight (Metric) | 35.834 kg |
