nVent MCS16065R5 - Modular Single Door, MCS with Plate, 1600x600x500mm, Light Gray, Mild Steel
nVent

MCS16065R5

UPC: 783510589356

Contact for Pricing

Overview

The nVent Hoffman MCS16065R5 is a modular, single-door, floor-standing enclosure constructed from robust mild steel. Measuring 1600x600x500mm, it offers IP55 protection against dust and water ingress, suitable for demanding industrial environments. Key features include a seam-welded frame with a 25mm hole pattern (DIN 43660) for mounting flexibility, a 4-point espagnolette locking system for security, and a removable roof panel. The enclosure is built with 1.5mm painted steel for the frame, rear, roof, and side panels, and 2mm painted steel for the door. It includes a 3mm galvanized steel mounting plate and 1mm galvanized steel bottom plates. The mounting plate is adjustable in depth by 25mm increments with the MPD02 accessory. Designed for combinability with other MCS enclosures, it facilitates scalable solutions. Typical applications include industrial control panels, automation systems, and power distribution. The MCS16065R5 is also IK10 rated for impact resistance. nVent Hoffman ensures reliable protection for critical electrical and electronic components.
  • Material: Frame: 1.5 mm painted steel. Door: 2 mm painted steel. Rear, roof and side panels: 1.5 mm painted steel. Mounting plate: 3 mm galvanized steel. Bottom plates: 1 mm galvanized steel.
  • Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern.
  • Door: Mounted with four hinges allowing left or right hand opening. Including door frame with 25 mm hole pattern.
  • Rear panel: Fitted by M6 torx screws. Standard facilities for rear door mounting. RD version comes with rear door instead of rear panel.
  • Side panels: Supplied as an accessory.
  • Roof panel: Removable.
  • Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories.
  • Bottom plates: Consists of three or four (D>600) pieces.
  • Mounting plate: Double folded and slides into position. Adjustable in depth by steps of 25 mm, with the MPD02 accessory. Supplied, attached on the outside of the enclosure packaging.
  • Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud.

Specifications

Color
Light Gray
IP Rating
IP55
Material
Mild Steel
Mounting Type
Floor-Stand
Series
MCS
Size
1600x600x500mm
Package Dimensions (L x W x H)
23.62 IN x 19.69 IN x 62.99 IN
Package Dimensions (L x W x H)
59.9948 cm x 50.0126 cm x 159.9946 cm
Package Weight (Imperial)
80.000 L
Package Weight (Metric)
36.288 kg
