nVent MCI18086R5 Floor standing, combinable, 1800x800x600, 1-door, Mild steel, Zinc plated, IP55
UPC: 783510493417
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Material: Frame: 1.5 mm steel plate. Door: 2 mm steel plate. Roof plate: 1.5 mm steel plate. Bottom plates: 1 mm galvanized steel. 19" profiles: 2 mm zinc plated steel
- Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern
- Rear door: Mounted with hinges, allowing left or right hand opening. Including door frame with 25 mm hole pattern
- Side panels: Supplied as an accessory
- Roof panel: Removable
- Lock: Espagnolette 4-point locking system. Does not interfere with the enclosure inner space. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories
- Bottom plates: Consists of three or four (D>600) pieces
- 19" profiles: Provides front and side universal 19" hole pattern. Adjustable in depth by steps of 25 mm
- Earthing: All panels are earthed through their fittings and are equipped with a separate earthing stud
- Finish: Frame, rear door and roof plate: RAL 7035 structured powder coating. 19" profiles: zinc plated steel
Specifications
Body Thickness | 0.06 in |
Body Thickness | 16 ga |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 23.62 in |
Depth | 600 mm |
Door Thickness | 14 ga |
Door Thickness | 0.08 in |
Finish | Powder Coating |
Height | 1,800 mm |
Height | 70.87 in |
IP Rating | IP55 |
Material | Mild Steel |
Material | Mild Steel, Zinc Plated |
Mounting Type | Floor Standing |
Protection Rating | IP55 |
Rack Units | 38 U |
Series | MCI |
Size | 1800x800x600 mm |
Type | Mild Steel Modular Industrial Enclosures |
Weight | 32 lbs./100ft |
Weight | 163.14 lb |
Width | 31.5 in |
Width | 800 mm |
Package Dimensions (L x W x H) | 71.24 IN x 31.87 IN x 32.12 IN |
Package Dimensions (L x W x H) | 180.9496 cm x 80.9498 cm x 81.5848 cm |
Package Weight (Imperial) | 196.600 L |
Package Weight (Metric) | 89.178 kg |
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
Frequently Asked Questions
What are the main dimensions of the MCI18086R5 enclosure?
The enclosure has a height of 70.87 inches, a width of 31.5 inches, and a depth of 23.62 inches.
What material is the MCI18086R5 enclosure made from?
The enclosure is constructed from mild steel, with zinc-plated steel for the 19" profiles.
What is the protection rating of the MCI18086R5 enclosure?
The enclosure complies with IP 55, TYPE 12, and IK 10 ratings when fitted with a plain front door and side panels.
How many Rack Units does the MCI18086R5 enclosure provide?
The enclosure offers 38U of Rack Units.
What type of locking system does the enclosure feature?
It features an Espagnolette 4-point locking system with a standard double-bit lock and a 3 mm insert.
What is the weight of the MCI18086R5 enclosure?
The enclosure weighs 163.14lb.
What color is the MCI18086R5 enclosure finished in?
The enclosure is finished in Light Gray with a RAL 7035 structured powder coating.
Are side panels included with the MCI18086R5 enclosure?
Side panels are supplied as an accessory and are required for closed sides.
How is the MCI18086R5 enclosure delivered?
It is delivered on a pallet with the frame, rear door, roof panel, bottom plates, and 19" profiles fitted.
What industry standards does the MCI18086R5 enclosure comply with?
The enclosure complies with cULus_UL Listed, CE, UKCA, and GOST industry standards.
