Contact for Pricing
Overview
- Includes two insulated copper wires with a ring terminal at each end, all installation hardware and instructions
- Green THHN insulation for clear identification
- Each wire terminated with a two-hole compression lug
- Ensures a low-impedance path to ground
- Includes fasteners for secure mounting
Specifications
Application | Controls and Drives |
Color | Green |
Color | Green/Yellow |
Connection Type | Compression Lug |
Finish | Insulated |
Material | Copper |
Modification Services | Yes |
Mounting Type | Fasteners |
Product Family | InLine |
Series | InLine Grounding Kit |
Size | #6 AWG x 7 strand |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | Electrical Accessories |
Weight | 0.2 lb. lb |
Weight | 0.21 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 8 IN x 6 IN x 0.5 IN |
Package Dimensions (L x W x H) | 20.32 cm x 15.24 cm x 1.27 cm |
Package Weight (Imperial) | 0.210 L |
Package Weight (Metric) | 0.095 kg |
A100125GR
PVC Wiring Duct (Carton Qty12), Bulletin A80 (Accessories - Misc. - Open Slot Wiring Duct & Accessories), Size/Dims: 1.00x1.25x72.00, Material: PlasticA200500GR
PVC Wiring Duct (Carton Qty12), Bulletin A80 (Accessories - Misc. - Open Slot Wiring Duct & Accessories), Size/Dims: 2.00x5.00x72.00, Material: Plastic
How to Install the LLGK Ground Kit
This guide provides step-by-step instructions for installing the LLGK ground kit safely and effectively.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Prepare the installation area
Ensure the installation area is clean and free of obstructions. Verify that all necessary tools and supplies are available.
- Mount the ground kit
Secure the ground kit to the designated area using the provided mounting screws. Ensure it is firmly attached and level.
- Connect the grounding wires
Strip the ends of the grounding wires and connect them to the terminal connectors. Use a multimeter to verify proper connections.
