Overview
- Description: For optimal weight distribution when lifting bayed enclosures. To be used in combination with baying bracket.
- Pack quantity: 2 pieces with mounting accessories.
- Advantage: lifting device ensuring optimal distribution of forces when lifting bayed enclosures
- Benefit: bayed floor standing enclosures can be lifted safely
- Includes 2 devices and mounting accessories, compliant with DIN 580
Specifications
Application | Factory Automation and Process Control; Controls and Drives; Power Distribution; Oil and Gas |
Application | Factory Automation and Process Control; Controls and Drives |
Color | Unpainted |
Consist of | Lifting Devices; Mounting Components and Instruction Manual |
Construction | 7 gauge |
Depth | 40 mm |
Depth | 1.57 in |
Enclosure Material | Mild Steel |
Finish | Zinc Plated |
Height | 2.36 in |
Height | 60 mm |
Material | Mild Steel |
Package Quantity | 2 |
Product Family | Free-Standing |
Size | 2.36 x 3.94 x 1.57 inch |
Thickness | 5 mm |
Thickness | 7 ga |
Type | Lifting |
Type | IEC Enclosure Accessories |
Weight | 1.76 lb |
Weight | 0.8 kg |
Width | 3.94 in |
Width | 100 mm |
Works With | IEC |
Package Dimensions (L x W x H) | 8 IN x 6 IN x 6 IN |
Package Dimensions (L x W x H) | 20.32 cm x 15.24 cm x 15.24 cm |
Package Weight (Imperial) | 1.760 L |
Package Weight (Metric) | 0.798 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the LC02 Enclosure
This guide provides step-by-step instructions for mounting and wiring the LC02 enclosure safely and effectively.
Estimated time: 1h
Tools needed:
Screwdriver, Torque wrench, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Cage nuts, Wire connectors
- Prepare the mounting surface
Ensure the mounting surface is clean and level. If mounting on a combustible surface, install a floor plate of at least 1.43 mm galvanized or 1.6 mm uncoated steel, extending at least 150 mm beyond the enclosure on all sides.
- Mount the enclosure
Secure the LC02 enclosure to the mounting surface using the provided mounting screws and cage nuts. Ensure the enclosure is level and firmly attached.
- Connect the wiring
Strip the ends of the wires and connect them to the appropriate terminals inside the enclosure. Use wire connectors to secure the connections.
- Verify electrical connections
Use a multimeter to check the continuity of the connections. Ensure there are no short circuits and that all connections are secure.
- Calibrate the enclosure
Adjust any necessary settings on the enclosure according to the manufacturer's specifications. Ensure all components are functioning correctly before closing the enclosure.
