Contact for Pricing
Overview
- Includes gasket and mounting hardware.
- Purchase Front Plate separately
- Concealed mounting screws for a clean, secure appearance
- Accepts front plate or plate with HMI cutout
- Designed for nVent InLine HMI enclosures
Specifications
Accepts Front Plate | LFP2525 |
Application | Controls and Drives |
Color | Light Gray |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 17 mm |
Depth | 0.67 |
Depth | 17 |
Finish | Powder Coated |
Height | 9.84 |
Height | 250 |
Height | 250 mm |
Material | Steel |
Material | Zinc |
Modification Services | Yes |
Mounting Type | Flush-Mounted |
Product Family | InLine |
Series | InLine HMI |
Size | 250x250mm |
Size | fits 250x250mm |
Thickness | 0.03 in |
Thickness | 0.8 mm |
Type | HMI Enclosure Systems |
Weight | 1.1 lb |
Width | 9.84 |
Width | 250 |
Width | 250 mm |
Window Size | 8.65 x 7.84 in |
Window Size | 220 x 200 mm |
Package Dimensions (L x W x H) | 9.5 IN x 9.5 IN x 0.75 IN |
Package Dimensions (L x W x H) | 24.13 cm x 24.13 cm x 1.905 cm |
Package Weight (Imperial) | 1.100 L |
Package Weight (Metric) | 0.499 kg |
How to Install the LBF2525 Controller
This guide provides step-by-step instructions for installing and configuring the LBF2525 Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Verify dimensions and clearances
Check the installation area to ensure it meets the required dimensions of 166mm x 160mm and that there are no obstructions.
- Mount the controller
Secure the LBF2525 controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Use wire connectors to attach the power and signal wires to the appropriate terminals on the LBF2525 controller. Ensure all connections are secure and insulated.
- Power on the controller
Turn on the power supply to the LBF2525 controller and verify that the power indicator is lit.
- Configure the settings
Access the configuration menu on the controller and set the desired parameters according to your application requirements.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure the controller operates within specified parameters.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
