Overview
- Attractive industrial design with minimal use of visible fasteners
- Level 1 Protection Includes: Protective coatings only applied to copper tubing and coils on the condenser (exterior facing) side as well as thermostat coatings
- Energy-efficient rotary compressor on most models
- Level 2 Protection Include: Everything that was coated in Level 1, plus protective coatings applied to the evaporator (interior facing ) side and an additional wrap around the thermostat
- Cleanable, reusable aluminum mesh filter included to protect coils for maximum cooling performance in dirty environments
- R407C, R513A or R134a refrigerants
- 115, 230 and 400/460 VAC 3-phase power input on most models
- Reliable mechanical thermostat on enclosure side of the unit
- All G-series come standard with two separate thermostats for cooling and heating when a heater is equipped
- Operating temperature range from -40 F/-40 C to 131 F/55 C
Specifications
Ambient Temperature | 40 Deg C |
Ambient Temperature | -40-131 °F |
Application | Corrosive Environments; Power Distribution; Controls and Drives |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Btu Rating | 12,000 |
Color | Unpainted |
Color | Brushed |
Corrosion Resistant | Yes |
Depth | 11.66 in |
Depth | 296 mm |
Finish | Brushed #4 |
Frequency Rating | 50/60 Hz |
Frequency Rating, Maximum | 60 Hz |
Frequency Rating, Minimum | 50 Hz |
Height | 1,338 mm |
Height | 52.69 in |
Material | Stainless Steel 316L |
Material | Stainless Steel 316 |
Max Current | 3.5 A |
Mounting | Side wall |
Mounting Type | Standard enclosure cutout |
NEMA Rating | 4X Watertight, corrosion-resistant |
Nominal Capacity Btu/h | 12,000 Btu/h |
Nominal Capacity Watts | 3,500 W |
Nominal Voltage | 460 V |
Number Of Phases | 1 |
Number Of Phases | 3 |
Operating Temperature | -40-131 |
Operating Temperature | -40-55 |
Operating Temperature | -40-55 °C |
Outdoor Installation | Yes |
Phase | 3 |
Phase | 3 Ph |
Poles | 3P |
Product Family | SpectraCool |
Protection Rating | NEMA Type 4X |
Refrigerant | R513A |
Remote Access Control | No |
Series | SpectraCool G52 |
Thickness | 51.40mm (2.024") |
Thickness | 18 ga |
Thickness | 1.21 mm |
Type | Air Conditioners |
Voltage AC | 400-460 V |
Voltage Rating | 460 V |
Voltage Rating | 400/460 V |
Weight | 152 lb |
Weight | 64 kg |
Width | 17.12 in |
Width | 435 mm |
Package Dimensions (L x W x H) | 19 IN x 16 IN x 54.5 IN |
Package Dimensions (L x W x H) | 48.26 cm x 40.64 cm x 138.43 cm |
Package Weight (Imperial) | 152.000 L |
Package Weight (Metric) | 68.947 kg |
How to Install the G52 Air Conditioner
This guide provides step-by-step instructions for installing and configuring the G52 Air Conditioner, ensuring proper functionality and safety.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Mounting gasket kit
- Inspect the air conditioner
Check for any visible damage and ensure the unit is functioning correctly before proceeding with the installation.
- Install mounting gaskets
Using the mounting gasket kit provided, apply gaskets to the air conditioner to ensure a watertight seal.
- Mount the air conditioner
Securely attach the air conditioner to the enclosure, taking care not to damage the mounting gaskets. Avoid dragging the unit to prevent tearing the gaskets.
- Wire the unit
Refer to the nameplate for electrical requirements and connect the unit to a properly grounded power supply. Ensure the circuit is fused appropriately.
- Verify electrical phasing
For 3-phase units, check that the phase monitor light is illuminated after applying power to confirm correct electrical phasing.
- Set thermostat
Adjust the thermostat to the desired cabinet temperature. Remove the protective plastic bushing to access the thermostat dial.
- Test the air conditioner
Allow the unit to run for 5 to 10 minutes to ensure proper operation, checking that the evaporator blower and compressor are functioning.
