nVent EKSS16104 - Floor stand., 1600x1000x400, Compact encl., 1-door, with MP, stainless 304, IP66
nVent

EKSS16104

UPC: 783510478438

Contact for Pricing

Overview

The nVent EKSS compact stainless steel floor standing enclosure, SKU EKSS16104, offers robust protection for critical industrial components in demanding environments. Engineered with a single door and a mounting plate (MP), this enclosure is constructed from high-grade 304 stainless steel, ensuring exceptional corrosion resistance and durability. Its IP66 rating signifies superior protection against dust ingress and high-pressure water jets, making it an ideal solution for applications where environmental contaminants pose a significant risk to equipment functionality and operational uptime. Designed for versatility, the EKSS range is available off-the-shelf in a wide array of standard sizes, including this 1600x1000x400mm model, to accommodate diverse installation requirements. The elimination of component failure due to environmental factors directly translates to reduced maintenance costs and minimized costly downtime, a critical consideration for any industrial operation. This enclosure's robust construction and sealing capabilities make it well-suited for a broad spectrum of industries and applications, from food and beverage processing plants where hygiene and washdown resistance are paramount, to outdoor installations exposed to harsh weather conditions, or chemical processing facilities where corrosive substances are prevalent. The inherent strength of stainless steel also provides a degree of mechanical protection against impacts and vandalism. Professionals choose nVent for their enclosures due to the manufacturer's long-standing reputation for quality, reliability, and innovative solutions in electrical protection. The EKSS series embodies this commitment, providing a dependable housing for sensitive electrical and electronic equipment, control systems, automation components, and power distribution units. Installation is straightforward, with the floor-standing design offering stability and ease of access for maintenance. The included mounting plate provides a secure and organized platform for mounting internal components, facilitating efficient wiring and system integration. When selecting an enclosure, factors such as environmental conditions, required internal space, accessibility, and protection ratings are crucial. The EKSS16104 excels in providing a high level of protection and a substantial internal volume for a compact footprint, making it a smart investment for safeguarding valuable industrial assets.
  • Material: AISI 304 pre-grained stainless steel / AISI 316L. Body and removable rear panel: 1.5 mm. Door: 2 mm. Bottom plate: 1.5 mm. Mounting plate: 3 mm galvanized steel.
  • Body: One piece enclosure body. Integrated depth profiles with hole pattern, allowing mounting plate adjustable in depth.
  • Door: Surface mounted with 4 hinges allowing left or right hand opening. Including door frame with 25 mm hole pattern and earthing studs.
  • Rear panel: Fitted by M6 torx screws. Standard facilities for rear door mounting.
  • Lock: External espagnolette 4-point locking system. Standard fitted double-bit 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories.
  • Bottom plates: One piece bottom plate, with injected polyurethane gasket to ensure maximum sealing.
  • Mounting plate: Double folded and slides into position. Adjustable in depth by steps of 25 mm with the MPD02 accessory. Mounting plate is supplied, attached on the outside of the enclosure packaging.
  • Earthing: Door is equipped with separate welded earthing studs and earthing to the frame can be accomplished by using the ECF.
  • Finish: 400 pre-grained stainless steel.
  • Protection: Complies with IP 66, TYPE 4X, 12, IK 10.

Specifications

Body Thickness
0.06 in
Body Thickness
16 ga
Depth
15.75 in
Depth
400 mm
Door Thickness
14 ga
Door Thickness
0.08 in
Finish
Brushed
Height
1,600 mm
Height
62.99 in
Material Quality
Stainless Steel 304
Material Quality
Stainless steel V2A
Panel Size
72.00 x 72.00 in
Panel Size
58.82 x 35.2 in
Protection Rating
IP66
Type
Stainless Steel Freestanding Industrial Enclosures
Weight
32 lbs./100ft
Weight
271.17 lb
Width
39.37 in
Width
1,000 mm
Package Dimensions (L x W x H)
63.37 IN x 39.75 IN x 40 IN
Package Dimensions (L x W x H)
160.9598 cm x 100.965 cm x 101.6 cm
Package Weight (Imperial)
316.500 L
Package Weight (Metric)
143.564 kg
