nVent DBDXK - Duplex Outlet Kit, Galvanized, Steel
nVent

DBDXK

UPC: 783510143787

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent DBDXK Duplex Outlet Kit, SKU DBDXK, is a robust and reliable solution designed to provide convenient power access within industrial enclosures and cabinets. Manufactured by nVent, a trusted leader in electrical protection and connection solutions, this kit ensures that essential equipment can be powered directly inside your control panels, junction boxes, or other critical infrastructure. This kit features a factory-mounted 15 Amp duplex outlet housed within a durable, three-sided, galvanized steel enclosure. The galvanized steel construction offers excellent corrosion resistance, making it suitable for a wide range of industrial environments, including those with potential exposure to moisture or corrosive elements. The enclosure is specifically designed to mount on the hinge side of a cabinet door, typically in the lower corner, ensuring it remains accessible without interfering with internal components or wiring. Installation is straightforward, with all necessary mounting hardware included, simplifying integration into existing or new cabinet designs. This pre-assembled unit eliminates the need for on-site outlet mounting and wiring within the enclosure, saving valuable time and reducing the potential for installation errors. Professionals in electrical contracting, automation, and industrial maintenance will appreciate the efficiency and reliability this kit offers. Key benefits of the nVent DBDXK Duplex Outlet Kit include: * **Enhanced Accessibility:** Provides convenient 15 Amp power directly within the cabinet for testing, diagnostics, or powering auxiliary devices. * **Durable Construction:** Galvanized steel enclosure offers superior protection against corrosion and physical damage. * **Simplified Installation:** Factory-mounted outlet and included hardware streamline the setup process. * **Space-Saving Design:** Compact enclosure mounts discreetly on the hinge side of the cabinet door. * **Trusted Manufacturer:** Backed by the quality and reliability of nVent. This outlet kit is ideal for a variety of applications, including: * Control panels and electrical enclosures * Industrial automation systems * Machine tool cabinets * Telecommunications equipment racks * Data centers and server rooms * Any application requiring safe and accessible internal power distribution. By incorporating the nVent DBDXK into your electrical design, you ensure a professional, safe, and efficient power solution for your critical equipment. The robust design and quality manufacturing from nVent guarantee long-term performance and peace of mind in demanding industrial settings. This product falls under the UNSPSC code 43223306, indicating its classification as an electrical outlet or receptacle assembly.
  • 15 Amp duplex outlet is factory-mounted in three-sided, plated steel enclosure
  • Outlet enclosure mounts on hinge side of door in lower corner of cabinet
  • Mounting hardware provided
  • Includes all necessary mounting hardware for easy installation
  • Manufactured by nVent, a trusted name in electrical solutions

Specifications

Application
Networking, Storage and Data Center
Color
Unpainted
Current Rating
15 A
Current Rating
15-15 A
Finish
Galvanized
Material
Steel
Material
Mild Steel
Modification Services
Yes
Mounting Type
Door-mounted
Thickness
16
Thickness
1.61
Thickness
1.61 mm
Type
Networking Accessories
Weight
0.8 lb
Package Dimensions (L x W x H)
6.1 IN x 4.3 IN x 4.6 IN
Package Dimensions (L x W x H)
15.494 cm x 10.922 cm x 11.684 cm
Package Weight (Imperial)
0.800 L
Package Weight (Metric)
0.363 kg
