nVent CSD242416SS - Concept Wallmount 1/4-Turn Latch Type 4X, 24x24x16, Brushed, Stainless 304

nVent CSD242416SS Concept Wallmount 1/4-Turn Latch Type 4X, 24x24x16, Brushed, Stainless 304

UPC: 783510345624

Documents & Media
Installation Instructions

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The nVent Concept Wallmount Enclosure (SKU: CSD242416SS) is a premium-grade stainless steel solution designed for demanding industrial environments where corrosion resistance, durability, and secure enclosure are critical. Constructed from high-quality 304 stainless steel with a brushed finish, this Type 4X/IP66-rated enclosure provides exceptional protection against water, dust, and chemical exposure, making it ideal for both indoor and outdoor applications. Engineered by nVent, a global leader in thermal management and electrical protection solutions, the Concept series combines robust construction with sleek, modern aesthetics for installations where both performance and visual appeal matter. Key features of the CSD242416SS include a flush quarter-turn latch system that ensures a secure closure while allowing quick and tool-free access to internal components. The wall-mount design facilitates straightforward installation in control panels, junction boxes, or equipment housings, while the brushed stainless steel finish delivers long-lasting resistance to corrosion, fingerprints, and environmental wear. With dimensions of 24x24x16 inches, this enclosure offers ample internal space for housing sensitive electronics, controls, or instrumentation while maintaining a compact footprint. Typical applications for the nVent Concept Wallmount Enclosure span multiple industries, including manufacturing, oil and gas, water treatment, telecommunications, and renewable energy. Professionals in these sectors rely on Type 4X-rated enclosures to safeguard critical components from harsh conditions such as high humidity, salt spray, chemical splashes, or extreme temperatures. The IP66 rating ensures complete protection against powerful jets of water and heavy dust ingress, making it suitable for outdoor installations in coastal areas, chemical plants, or wastewater facilities. Selecting the right enclosure for an industrial application requires careful consideration of environmental conditions, material compatibility, and access requirements. The 304 stainless steel construction of the CSD242416SS offers excellent resistance to a wide range of chemicals, including acids and alkalis, while maintaining structural integrity in temperatures from -40°C to 125°C. The quarter-turn latch mechanism provides a secure seal without the need for additional tools, reducing maintenance time and improving operational efficiency. For installations requiring frequent access, the flush latch design minimizes snag hazards and maintains a clean, professional appearance. nVent’s reputation for engineering excellence is built on decades of innovation in thermal and electrical protection solutions. The Concept series, including the CSD242416SS, reflects the company’s commitment to delivering products that meet the highest standards of performance, safety, and reliability. Whether deployed in a factory automation system, a telecom shelter, or a renewable energy substation, this enclosure provides the durability and protection needed to ensure uninterrupted operation. Trusted by engineers, contractors, and facility managers worldwide, nVent enclosures are a preferred choice for projects where failure is not an option.
  • Minimum-width body flange provides maximum body opening
  • External formed 90-degree body flange
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for direct mounting or for optional external mounting brackets
  • Type 316 stainless steel hidden hinges promote clean aesthetic appearance
  • Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins
  • Provision on door (except when B = 12 inch (305mm)) for thermoplastic data pocket
  • Provision on door (except when B = 12 inch (305mm)) for optional doorstop kit
  • Quarter-turn latches furnished with flush slotted insert
  • Seamless foam-in-place gasket

Specifications

Application
Controls and Drives;Corrosive Environments
Application
Corrosive Environments; Controls and Drives
Body Thickness
14 ga
Body Thickness
1.98 mm
Body Thickness
16 ga
Color
Unpainted
Conductive Panel
CP2424G
Depth
406 mm
Depth
16 IN
Door Thickness
14 ga
Door Thickness
16 ga
Door Thickness
1.59 mm
Finish
Brushed #4
Height
1,067 mm
Height
24 in
IP Rating
IP66
Latch Quantity
2
Latch Type
Quarter-turn
Material
Stainless Steel 304
Material Quality
Stainless Steel 304
Material Quality
Stainless steel V2A
Modification Services
Yes
Mounting
Wall Mounting Brackets Available
Mounting
22.50 x 22.50 in
NEMA Rating
12
NEMA Rating
12 Indoor, dust-resistant
Panel
CP2424
Panel Size
564 x 564 mm
Panel Size
22.20 x 22.20 in
Product Family
Concept
Protection Rating
NEMA Type 3R
Protection Rating
NEMA Type 12
Style
Quarter-turn
Type
Stainless Steel Wall Mounted Industrial Enclosures
Type Number
Type 3R
Weight
57 lb
Width
610 mm
Width
24 IN
Package Dimensions (L x W x H)
29 IN x 25.25 IN x 18.5 IN
Package Dimensions (L x W x H)
73.66 cm x 64.135 cm x 46.99 cm
Package Weight (Imperial)
57.000 L
Package Weight (Metric)
25.855 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.

BX4

Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
Locking using CASTELL K key operated lock (not supplied) Fuserbloc Sirco

36297702

Locking using CASTELL K key operated lock (not supplied) Fuserbloc Sirco
External operation handle 0-1 type S01 Red Nema 4,4x

140E2911

External operation handle 0-1 type S01 Red Nema 4,4x
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey

LT20D-NEW

1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey

LN43DA

1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A
5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

FF12D24NN53

5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55
12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

FF20A115UE1

12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

How to Install the CSD242416SS Wall-Mount Enclosure

Follow these instructions to properly mount and install your CSD242416SS wall-mount enclosure.

Estimated time: 1h

Tools needed:

Drill, Level, Measuring tape, Screwdriver, Wrench or socket set

Supplies needed:

Mounting hardware (screws, anchors, bolts), Gasket (if applicable), Sealing fittings (if applicable)

  1. Select Mounting Location

    Choose a suitable location for the enclosure. Ensure the mounting surface is strong enough to support the weight of the enclosure and its contents. Consider environmental factors such as temperature, humidity, and potential exposure to corrosive elements. Refer to the datasheet for specific environmental ratings.

  2. Prepare the Enclosure

    If necessary, install any required accessories such as internal mounting panels, gland plates, or door stops. Ensure the gasket is properly seated around the door flange for a watertight seal. If using sealing fittings for cable entry, install them according to their specific instructions.

  3. Mark Mounting Holes

    Hold the enclosure in the desired position against the mounting surface. Use a level to ensure it is straight. Mark the locations for the mounting holes through the designated mounting points on the back of the enclosure or the internal mounting panel.

  4. Drill Mounting Holes

    Remove the enclosure from the mounting surface. Drill the mounting holes at the marked locations. If mounting to a concrete or masonry surface, use appropriate masonry bits and install anchors. If mounting to a metal surface, ensure the holes are appropriately sized for the chosen fasteners.

  5. Mount the Enclosure

    Position the enclosure over the drilled holes. Secure the enclosure to the mounting surface using appropriate hardware (screws, bolts, etc.). Ensure the enclosure is firmly attached and does not move. Use a wrench or socket set for tightening bolts as needed.

  6. Install Equipment and Wiring

    Install any internal equipment according to its specific instructions. Route wiring through the appropriate conduit or cable entries, ensuring proper strain relief and sealing. Refer to the wiring diagrams provided with the equipment and the enclosure datasheet for guidance on wire management and sealing.

  7. Final Inspection

    Close and latch the enclosure door securely. Verify that all seals are properly engaged and that the enclosure is watertight or weatherproof as required by its rating. Double-check that all mounting hardware is tight and that the installation is secure.
