nVent CSD242410 - Concept Single-Door Enclosure, 24.00x24.00x10.00, Gray, Steel
nVent

CSD242410

UPC: 783510374990

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent CSD242410 Concept Single-Door Enclosure is a robust and elegantly designed solution for protecting sensitive electrical and electronic components in demanding industrial environments. Engineered for superior durability and ease of use, this wall-mount enclosure meets Type 4 and 12 standards, ensuring protection against dust, water, and impact. Its streamlined styling, featuring flush quarter-turn latches, not only enhances its aesthetic appeal but also contributes to a secure and reliable seal. The durable, attractive gray finish provides excellent corrosion resistance, making it suitable for a wide range of applications across various industries. Crafted from high-quality steel, the CSD242410 offers exceptional structural integrity to safeguard your valuable equipment. The single-door design facilitates straightforward access for installation, maintenance, and operational checks. nVent, a globally recognized leader in electrical enclosure solutions, leverages decades of expertise to deliver products that meet stringent industry requirements and exceed customer expectations. This enclosure is an ideal choice for applications requiring reliable protection for control panels, instrumentation, automation systems, and other critical electrical assemblies. Key features and benefits of the nVent CSD242410 include: * **Robust Construction:** Fabricated from durable steel for long-lasting performance and protection. * **Environmental Sealing:** Type 4 and 12 rated, providing superior defense against dust, water ingress, and impact. * **Streamlined Aesthetics:** Modern design with flush quarter-turn latches for a clean and professional look. * **Ease of Access:** Single-door configuration simplifies installation and maintenance procedures. * **Versatile Mounting:** Designed for wall-mount applications, offering flexible placement options. * **Trusted Manufacturer:** Backed by the quality and reliability of nVent, a leader in enclosure technology. This enclosure is commonly deployed in sectors such as manufacturing, process control, telecommunications, and building automation. Its dimensions of 24.00 inches in height, 24.00 inches in width, and 10.00 inches in depth provide ample space for a variety of components. When selecting an enclosure, professionals prioritize factors like ingress protection ratings, material durability, ease of installation, and manufacturer reputation. The nVent CSD242410 excels in all these areas, offering a dependable and cost-effective solution for critical equipment protection. The UNSPSC code 39121324 further categorizes this product within the electrical enclosure market, highlighting its specific industrial application. Manufactured in the USA, this enclosure embodies quality craftsmanship and adherence to rigorous production standards.
  • Seams continuously welded and ground smooth
  • Corner-formed doors
  • Simple easy-to-remove and install hinge pins with built-in captivation clip
  • High-torque threadless studs and fasteners on door
  • Minimum-width body flange provides maximum door opening (210 degrees)
  • Door opens 210 degrees
  • External formed body flange
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for optional external wall-mount brackets
  • Removable door with hidden hinges for clean, aesthetic appearance

Specifications

Application
Controls and Drives
Body Thickness
1.52 mm
Body Thickness
16 ga
Color
Gray
Color Code
ANSI 61
Concept Panel
CP2424
Conductive Concept Panel
CP2424G
Depth
10 IN
Depth
254 mm
Door Thickness
1.9 mm
Door Thickness
14 ga
Finish
Powder Coated
Height
24 in
Height
610 mm
IP Rating
IP66
Latch Quantity
2
Latch Style
Quarter-turn
Latch Type
Quarter-turn
Material
Steel
Material
Mild Steel
Modification Services
Yes
Mounting
Wall Mounting Brackets Available
Mounting
22.50 x 22.50 in
Mounting Type
Wall-mount
Nema Rating
Type 4, 12
NEMA Rating
12
NEMA Rating
12 Indoor, dust-resistant
Panel Size
564 x 564 mm
Panel Size
22.20 x 22.20 in
Product Family
Concept
Protection Rating
NEMA Type 12
Series
Concept
Size
24.00x24.00x10.00 in
Size
24.00x24.00x10.00
Type
Mild Steel Wall Mounted Industrial Enclosures
Type Number
Type 4
Weight
44 lb
Width
610 mm
Width
24 IN
Package Dimensions (L x W x H)
28.7 IN x 25.3 IN x 12.3 IN
Package Dimensions (L x W x H)
72.898 cm x 64.262 cm x 31.242 cm
Package Weight (Imperial)
44.000 L
Package Weight (Metric)
19.958 kg
