Contact for Pricing
Overview
- Painted white or conductive finish
- Include a formed flange along any side that is longer than 22.20 in (564 mm)
- Optional wood panels are made of 3/4-in plywood, pre-cut and pre-drilled to install on panel mounting studs in the rear of the cabinet
- Facilitates component mounting and cable management
- Ideal for industrial, automation, and data center applications
Specifications
Application | Datacom and Telecom Equipment; Networking, Storage and Data Center |
Color | White |
Finish | Powder Coated |
Gauge | 12 ga |
Height | 1,351 mm |
Height | 53.2 in |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Product Family | Concept |
Series | Concept Panel |
Size | 56.00x20.00 inch |
Size | 56.00x20.00 inch Enclosure |
Thickness | 12 in |
Thickness | 2.66 mm |
Type | Industrial Panels and Panel Accessories |
Type | Painted Steel |
Weight | 31.4 lb |
Width | 18.2 in |
Width | 462 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 54.5 IN x 18.75 IN x 1.5 IN |
Package Dimensions (L x W x H) | 138.43 cm x 47.625 cm x 3.81 cm |
Package Weight (Imperial) | 31.400 L |
Package Weight (Metric) | 14.243 kg |
