Contact for Pricing
Overview
- Kits include slide mechanisms and hardware
- Use two kits when enclosure has six collar studs for mounting panel
- Kit catalog numbers ending in 2 contain two slide mechanisms; catalog numbers ending in 4 contain four slide mechanisms
- Designed for 8.00-inch (203 mm) deep CONCEPT enclosures
- Durable plated steel construction
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Plated |
Fits Concept Enclosure | When C = 8.00 in |
Fits Concept Enclosure | When C = 203 mm |
Fits Depth | 9.84 in |
Fits Depth | 8 in |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Product Family | Concept |
Size | fits 8.00 deep + in |
Type | Industrial Panels and Panel Accessories |
Weight | 1.64 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 13.8 IN x 4.5 IN x 3 IN |
Package Dimensions (L x W x H) | 35.052 cm x 11.43 cm x 7.62 cm |
Package Weight (Imperial) | 1.640 L |
Package Weight (Metric) | 0.744 kg |
How to Install the CAM84 Controller
This guide provides step-by-step instructions for the installation and initial setup of the CAM84 Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the CAM84 controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the ends of the wires. Connect the power and signal wires to the appropriate terminals on the CAM84 controller, ensuring correct polarity.
- Verify connections
Use a multimeter to check the voltage at the terminals to ensure proper power supply. Confirm that all connections are secure and correctly wired.
- Configure the controller
Access the CAM84 configuration interface and input the necessary parameters for your application, such as operational modes and thresholds.
- Calibrate the system
Follow the calibration procedure outlined in the CAM84 manual to ensure accurate readings and performance. Adjust settings as necessary.
